Nexperia Zener Diode 20V 365mW Surface Mount 2-Pin DFN1006BD-2 BZX8850S-C20-QYL

Nexperia BZX8850S-C20-QYL Zener Diode offers high-performance voltage regulation for precision electronics, featuring a 20V nominal Zener voltage and a ±5% tolerance. Designed for single-element configuration, this diode is ideal for demanding applications in industrial, automotive, and portable electronics due to its robust specifications. The DFN1006BD-2 surface mount package is engineered for easy integration, with side-wettable flanks for improved soldering reliability and an ultra-compact footprint measuring 1mm × 0.47mm.

With a maximum power dissipation of 365mW, this Zener diode ensures reliable operation under various conditions. The device is specified at a low test current of 50μA, making it suitable for low-bias and portable battery-powered systems where efficiency is paramount. It is AEC-Q101 qualified and supports a wide operating temperature range from -55°C to 150°C, guaranteeing stability in extreme environments.

Additional features include low maximum reverse leakage current (50nA), a high maximum Zener impedance (225Ω), and a typical voltage temperature coefficient of 14.4mV/K. These characteristics collectively ensure consistent regulation performance across temperature variations and long-term durability on compact and densely populated PCBs.

The BZX8850S series is widely adopted in industrial automation, laboratory instrumentation, automotive electronics, and RF applications where space-saving and accurate voltage regulation are essential. The surface-mount nature allows for streamlined automated assembly, improving both efficiency and reliability in manufacturing environments.

20V nominal voltage with ±5% tolerance for stable regulation. 365mW maximum power dissipation supports robust designs. DFN1006BD-2 package for ultra-small surface mounting. Single-element configuration for straightforward integration.

Low test current, ideal for portable and battery-driven devices. Automotive standard (AEC-Q101) compliance for expanded use cases. Operating temperature range of -55°C to 150°C. Ultra-low reverse leakage and high Zener impedance for precision control.

Common industrial and laboratory uses include voltage reference, transient suppression, and biasing in sensor circuits, power management modules, and telecommunications systems. Its reliable surface-mount design and robust electrical parameters make it suitable for commercial electronics, manufacturing process controls, and advanced PCB assemblies.
