Weidmüller BUF 10.16IT/03/180 AG BK BX PCB Connector, 3-Contact, 10.16 mm Pitch, 1 Row, 34A, 600V, Polyamide 2493400000
Specifications
| Country of Origin | Romania |
|---|---|
| Voltage | 600V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | 180° |
| Current | 34A |
| Length | 28.9mm |
| Depth | 39.5mm |
| Width | 30.48mm |
| Housing Material | Polyamide Fibreglass |
| Series | BUF 10.16IT/03/180 AG BK BX |
| Number of Rows | 1 |
| Pitch | 10.16mm |
| Number of Poles | 2 |
| Standards/Approvals | Crlus, RoHS |
| Number of Contacts | 3 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 2.5mm² |
| Maximum Wire Size mm² | 16mm² |
| Minimum Wire Size AWG | 12AWG |
| Maximum Wire Size AWG | 4AWG |
| Wire Connection Method | Push-in with Actuator |
| Pitch in inches (P) | 0.4 inch |
| Conductor outlet direction | 180° |
Key Features
- Robust PCB connector designed for secure wiring in industrial applications.
- Features 3 contacts and a 10.16 mm pitch for reliable connection.
- Supports high current up to 34A and voltage rating of 600V.
- Polyamide fibreglass housing for enhanced durability and insulation.
- Male connector type with push-in actuator for tool-free wire connection.
- Works with wire sizes from 2.5 mm² to 16 mm² and AWG 12 to AWG 4.
- Single row configuration and 180° orientation for easy board placement.
- Compliant with RoHS and cRLus standards for quality assurance.
Product Description
Weidmüller BUF 10.16IT/03/180 AG BK BX PCB Connector, model 2493400000, is specifically engineered for professional PCB applications requiring high reliability and rapid installation. It is a robust 3-contact connector with a pitch of 10.16 mm, making it suitable for various electronic and industrial circuit connections.
Robust PCB connector designed for secure wiring in industrial applications. Features 3 contacts and a 10.16 mm pitch for reliable connection. Supports high current up to 34A and voltage rating of 600V. Polyamide fibreglass housing for enhanced durability and insulation.
Male connector type with push-in actuator for tool-free wire connection. Works with wire sizes from 2.5 mm² to 16 mm² and AWG 12 to AWG 4. Single row configuration and 180° orientation for easy board placement. Compliant with RoHS and cRLus standards for quality assurance.
Compact size: 28.9 mm length, 30.48 mm width, 39.5 mm depth.
The push-in technology with actuator simplifies wire-ready connections, allowing for direct and tool-free connection of solid wires and crimped wire-end ferrules. Single-hand operation and automatic secure connections are possible thanks to the Snap-On mechanism. The connector is constructed from polyamide fibreglass for strength and electrical insulation, and features black coloration for easy identification.
This model is rated to carry 34A and withstand up to 600V, which is ideal for power circuits and control wiring in industrial environments. Wire size flexibility from 2.5 mm² to 16 mm² (AWG 12 - AWG 4) accommodates stranded and rigid conductors, enhancing compatibility with a wide range of wire types. The 180° orientation and single row design facilitate efficient placement on PCBs with straightforward cable routing.
BUF series connectors meet cRLus and RoHS standards, ensuring compliance with safety and environmental regulations. The compact dimensions - 28.9 mm length, 39.5 mm depth, 30.48 mm width - make it suitable for tight PCB layouts without sacrificing performance.
Applications include industrial automation, control systems, power distribution boards, HVAC electronics, and commercial installations where reliability, ease of use, and safe connections are critical.
Explore more PCB Connectors for industrial and electronics integration at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 34A.
It has a voltage rating of 600V.
It accommodates wire sizes from 2.5 mm² to 16 mm² and AWG 12 to AWG 4.
The pitch for this model is 10.16 mm.
It utilizes a push-in connection method with an actuator for tool-free wire connection.
This model features 3 contacts.
The dimensions are 28.9 mm in length, 30.48 mm in width, and 39.5 mm in depth.
It has a 180° orientation for easy board placement.
Yes, it is compliant with RoHS and cRLus standards.
The housing is made from polyamide fibreglass, providing enhanced durability and insulation.
It features a single row configuration.
It is suitable for applications in industrial automation, control systems, power distribution boards, and HVAC electronics.
