Wurth Elektronik WR-FPC 0.5 mm Pitch 50 Way Horizontal Female FPC Connector, Solder 687150149022
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 50, 50V ac |
| Brand | Wurth Elektronik |
| Orientation | Horizontal |
| Current | 500mA |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Phosphor Bronze |
| Series | WR-FPC |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | FPC |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Locking Mechanism | Flip-lock hinge |
| Pitch | 0.5mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 50 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
| Contact Position | Bottom |
Key Features
- FPC connector with 0.5 mm pitch and 50 contact positions for reliable circuit connections.
- Horizontal surface mount configuration enhances board layout flexibility.
- Female gender connector with ZIF insertion force and hinged flip-lock actuator for secure cable locking.
- Contact material is phosphor bronze, plated with tin over nickel for robust conductivity.
- Supports up to 500 mA current and 50 V AC voltage, suitable for miniaturized displays and keyboards.
- Polyamide housing ensures lightweight yet durable construction for space-sensitive electronic designs.
- Operating temperature range from -40°C to 105°C for versatile industrial environments.
- Solder termination and retention feature aids in PCB mounting reliability.
Product Description
Wurth Elektronik 687150149022 WR-FPC 0.5 mm Pitch 50 Way Horizontal Female FPC Connector, Solder is engineered for high-density, space-efficient PCB connections in advanced electronic assemblies. Featuring a horizontal surface mount form factor, this connector provides exceptional flexibility in board layout, supporting miniaturized device designs and applications requiring reliable flex cable termination.
With a compact 0.5 mm pitch and 50 contact positions, the WR-FPC series ensures robust signal integrity and facilitates secure wire-to-board connectivity. The female gender connector incorporates a Zero Insertion Force (ZIF) flip-lock actuator, allowing for easy cable insertion and secure locking, critical in precision electronics such as displays and keyboards. The bottom contact configuration maximizes contact area, ensuring stable electrical performance even in demanding environments.
Contacts are made from phosphor bronze and feature tin over nickel plating, delivering high conductivity and durability - ideal for frequent mating cycles and stable signal transmission. Designed for surface mount installation, the connector includes a solder retention feature to maintain positioning during the reflow soldering process, contributing to assembly reliability and ease of manufacturing.
Rated up to 500 mA and 50 V AC, this FPC connector is suitable for a wide range of industrial and commercial applications, including small display connections, keyboard interfaces, and other compact electronics. The polyamide housing provides lightweight protection and ensures the connector’s mechanical strength in space-constrained devices, supporting operational temperatures between -40°C and 105°C.
Applications span industrial control panels, laboratory instrumentation, consumer electronics, medical devices, and automotive displays, where precise, secure, and high-density wire-to-board connections are essential.
Choose from PCB Connectors and electronic connection solutions in the Electronics & Electricals category or browse the full WR-FPC series from Wurth Elektronik for advanced engineering needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a 0.5 mm pitch and has 50 contact positions, designed for high-density PCB connections.
It is rated for a maximum current of 500 mA and a voltage of 50 V AC, making it suitable for various applications.
The contacts are made from phosphor bronze and are plated with tin over nickel, while the housing is constructed from polyamide.
This unit features a flip-lock hinge mechanism, which provides secure cable locking and easy insertion.
It operates within a temperature range of -40°C to 105°C, suitable for diverse industrial environments.
It uses solder termination, which aids in PCB mounting reliability and stability during assembly.
The connector is designed for horizontal surface mount installation, enhancing layout flexibility on PCBs.
It is suitable for applications such as miniaturized displays, keyboards, industrial control panels, and medical devices.
This model features a Zero Insertion Force (ZIF) design, allowing for easy cable insertion without excessive force.
The connector has a compact design with a 0.5 mm pitch and 50 contacts, but specific dimensions are not provided in the data.
Yes, it includes a solder retention feature that helps maintain positioning during the reflow soldering process.
The country of origin for this connector is China.
