Samtec TSW Series Straight Through Hole Pin Header 2 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-102-06-F-S

The Samtec TSW-102-06-F-S is a straight, through-hole, single-row pin header designed for use in a variety of electronic circuits. This model provides reliable connectivity with two male contacts spaced at a 2.54 mm pitch, making it highly compatible with standard PCB layout requirements in both prototyping and production environments.

This pin header features contacts made from high-quality phosphor bronze, plated with gold to ensure low contact resistance, corrosion resistance, and stable electrical performance over the operating life of the device. The insulation body is moulded from black glass-filled polyester, giving the component excellent mechanical strength and insulating properties to maintain signal integrity and prevent short circuits during operation.

The TSW-102-06-F-S supports through-hole mounting, offering secure soldered connections to the printed circuit board, which makes it well-suited for applications where robustness and long-term mechanical stability are required. Its single row and unshrouded configuration allow for easy mating with compatible connectors, providing straightforward integration in board-to-board connections and signal routing tasks.

Rated for operation in demanding conditions, the header withstands temperatures from -55°C up to 125°C (with gold plating). It is capable of handling voltages up to 550 V (AC), making it suitable for low to moderate power circuit designs. Contact gender is male, supporting typical board interface requirements for signal and low- to moderate-current transmission. Terminations are of the solder type, streamlining assembly for electronics manufacturing or R&D use.

The gold or tin over nickel contact plating, with a nominal thickness of 1.27 μm (50 μ"), enhances durability and performance in harsh environments. This feature ensures the header maintains connectivity and signal reliability after repeated insertions, making it ideal for PCBs that require frequent assembly and rework.

Typical applications for the TSW-102-06-F-S include instrumentation, industrial controls, consumer electronics, automation devices, and embedded systems, where reliable and compact board-to-board or PCB-to-cable connections are needed. It can also be used in development kits, evaluation boards, and various prototyping projects requiring a robust and easy-to-use pin header.

Choose this Samtec pin header for efficient, reliable, and compliant PCB connectivity in industrial, laboratory, embedded, or general electronic assembly projects. For more innovative interconnect solutions, explore the broader selection of PCB Pin Headers and Samtec products within the EnvMart catalogue.
