Samtec ESQ Series Straight Through Hole PCB Socket, 26-Contact, 2 Row, 2.54 mm Pitch, 5.7A, Solder, Black ESQ-113-12-L-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec ESQ Series Straight Through Hole PCB Socket, 26-Contact, 2 Row, 2.54 mm Pitch, 5.7A, Solder, Black ESQ-113-12-L-D

Name: Samtec ESQ Series Straight Through Hole PCB Socket, 26-Contact, 2 Row, 2.54 mm Pitch, 5.7A, Solder, Black ESQ-113-12-L-D
Brand: Samtec
SKU: 83709
Price: 5.89 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	515V
Brand	Samtec
Orientation	Straight
Current	5.7A
Model	ESQ-113-12-L-D
Mount Type	Through Hole
Housing Material	Black Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	ESQ
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	2
Max Cycles	100
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	26
Connector System	Board-to-Board
Normal Force	125 g

Key Features

High-performance PCB socket with 26 contacts designed for board-to-board connections.
Features straight orientation for direct through-hole mounting to PCBs.
2.54 mm pitch ensures compatibility with standard pin layouts in electronic assemblies.
Supports up to 5.7A per contact, suitable for robust power and signal transmission.
Terminated by solder for reliable, permanent connection to PCB pads.
Housing made from black glass-filled polyester for enhanced durability and insulation.
Phosphor bronze contacts with gold plating provide superior corrosion resistance and conductivity.
Operates across a wide temperature range from -55°C to 125°C, ideal for demanding environments.

Product Description

Samtec ESQ-113-12-L-D is an advanced PCB socket specifically built for board-to-board interconnections, providing reliable connectivity for electronic and industrial applications. Featuring 26 contacts arranged in 2 rows with a 2.54 mm pitch, this socket is compatible with common PCB designs and offers straight orientation for easy integration into printed circuit boards.

The socket is engineered for through-hole mounting and utilizes solder termination, enabling secure and permanent attachment to PCB pads. With a current rating of 5.7A per contact and a voltage capacity up to 515V, it is well-suited for both signal and power transmission in high-demand environments. The housing is constructed from robust black glass-filled polyester, providing mechanical stability and insulation, while phosphor bronze contacts with gold plating ensure optimal conductivity and resistance to corrosion.

Operational flexibility is supported by a wide temperature range of -55°C to 125°C, making the ESQ-113-12-L-D suitable for industrial, electronic manufacturing, automotive, and lab setups requiring stable performance under harsh conditions. The socket is part of the ESQ elevated series and offers standard and low insertion force contacts for PC/104 applications with 0.635 mm square tails.

Typical use cases include PCB interconnect systems in industrial controllers, instrumentation, automation panels, and commercial electronics. Its reliable board-to-board connector system supports precise alignment and robust electrical contact for devices where durability and stable operation are critical.

This product does not explicitly mention certifications but is built to industrial quality standards for electronics and electricals. Customers can browse other PCB sockets and related Samtec connectors for tailored solutions in complex assemblies.

Explore more PCB sockets and Samtec interconnect solutions in the PCB Socket segment on EnvMart.
