SMC Pneumatic Piston Rod Cylinder Double Acting CDU Series 40 mm Bore, 40 mm Stroke, Aluminium Alloy, CDUK20-40D

The SMC CDUK20-40D Pneumatic Piston Rod Cylinder is engineered for demanding industrial environments requiring robust pneumatic actuation and precise motion control. With its 40 mm bore and 40 mm stroke, this cylinder delivers reliable double acting movement, making it ideal for automation, material handling, and custom machinery in manufacturing and assembly lines.

This cylinder is constructed from high-quality aluminium alloy, ensuring corrosion resistance and structural integrity during long-term operation. The piston rod features a metric male thread for convenient connectivity to a wide range of fixtures and end tools. The single rod arrangement offers stability and efficient energy transfer in reciprocating actions.

The CDUK20-40D incorporates a rubber bumper cushioning system to minimize noise and absorb shock during operation, supporting higher speed movements up to 500 mm/s while maintaining smooth performance. The cylinder is designed for precise, space-saving mounting, with a compact length of 115 mm, allowing it to fit into machinery where space is limited.

Its double acting configuration enables reliable forward and backward motion for tasks such as pushing, pulling, clamping, or positioning. The operational temperature limit of 60°C makes it suitable for a broad spectrum of challenging environments, including industrial automation, factory assembly, and pneumatic control systems.

Corrosion-resistant aluminium alloy construction for enhanced durability. Double acting mechanism optimizes reciprocating pneumatic tasks. 40 mm stroke length adapts to versatile movement requirements. Rubber bumper cushioning for shock absorption and reduced acoustic impact.

Metric male piston rod threading facilitates secure and flexible connections. High-speed performance up to 500 mm/s for dynamic applications. Designed for space-saving machine integration with 115 mm cylinder length. Operational temperature range supports high-demand industrial conditions.

Typical applications include industrial machinery, automation systems, pick-and-place units, assembly lines, and other pneumatic actuation contexts requiring smooth and adjustable motion. For further exploration of the SMC CDU Series and pneumatic actuation solutions, browse more products and options on EnvMart.
