Samtec Straight Through Hole PCB Socket, 24 Contacts, 1 Row, 2.54 mm Pitch, Solder, SSW-124-01-G-S

The Samtec SSW-124-01-G-S is a high-performance straight through hole PCB socket, designed for reliable board-to-board connections in diverse electronic applications. This socket features 24 contacts arranged in a single row with a precise 2.54 mm pitch, making it compatible with standard PCB layouts and suitable for dense component installations where space efficiency is critical.

Engineered with a robust liquid crystal polymer housing, the socket ensures high mechanical strength and thermal stability, while the contact system utilizes the Tiger Buy™ design for consistent retention and secure electrical connectivity. The contacts are fabricated from bronze and benefit from a gold plating, enhancing electrical conductivity and safeguarding against corrosion over many mating cycles.

The SSW-124-01-G-S supports up to 4.7 A current and a maximum voltage of 655 V, positioning it as an excellent choice for applications that demand robust signal or power transmission. Its straight orientation enables straightforward integration on printed circuit boards, and through-hole mounting simplifies the soldering process for both automated and manual assembly lines.

This model is capable of withstanding challenging environmental conditions, operating reliably in temperatures ranging from -55°C to 125°C. The female contact configuration provides versatile mating compatibility with compatible pin headers or .025 in. square posts. Both standard and low insertion force options are supported, with solder tails offering strong mechanical anchoring and secure connection integrity.

Use cases for the Samtec SSW-124-01-G-S include a wide array of industrial control systems, instrumentation, telecommunications, and commercial electronics where quality and dependability are paramount.

This product is a core component for assembling custom electronic boards and is ideal for prototyping, maintenance and repair, and new electronic product development where robust, high-quality PCB socket interconnects are a must.
