Samtec Straight Through Hole PCB Socket, 20 Contacts, 1 Row, 2.54 mm Pitch, Solder, SSW-120-01-T-S

Free Delivery in India | Lowest Global Shipping Charges

Samtec Straight Through Hole PCB Socket, 20 Contacts, 1 Row, 2.54 mm Pitch, Solder, SSW-120-01-T-S

Name: Samtec Straight Through Hole PCB Socket, 20 Contacts, 1 Row, 2.54 mm Pitch, Solder, SSW-120-01-T-S
Brand: Samtec
SKU: 82112
Price: 2.82 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	655V
Brand	Samtec
Orientation	Straight
Current	4.7A
Model	SSW-120-01-T-S
Mount Type	Through Hole
Special Features	Standard and low insertion force contacts with standard solder tails
Housing Material	Liquid Crystal Polymer
Contact Material	Bronze
Series	SSW
Termination	Through-hole, surface mount
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	Socket Strip
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	20
Contact Gender	Female
Connector System	Board-to-Board
Contact System	Tiger Buy™

Key Features

Designed as a single row socket strip with 20 female contacts and through-hole mounting.
Supports a pitch of 2.54 mm ensuring compatibility with standard PCB layouts.
Accommodates up to 4.7 A current and operates up to 655 V voltage for robust board-to-board connections.
Constructed from liquid crystal polymer housing and tin-plated bronze contacts for durability and electrical reliability.
Suitable for both standard and low insertion force applications, with Tiger Buy contact system for high retention.
Endures temperatures from -55°C to 105°C, making it viable for a wide range of industrial and electronic environments.

Product Description

The Samtec SSW-120-01-T-S is a high-performance straight through hole PCB socket designed for secure and reliable board-to-board connections across industrial and electronics applications. Engineered with 20 female contacts arranged in a single row and featuring a standard 2.54 mm pitch, this socket is ideal for use in circuit board assembly where high retention and cost-effective connectivity are paramount.

This PCB socket utilizes a robust Tiger Buy™ contact system, offering both standard and low insertion force contacts, and is specially constructed to withstand demanding environments. Its bronze contacts are finished with tin plating to ensure long-term electrical integrity, while the housing is fabricated from liquid crystal polymer to maintain dimensional stability at elevated temperatures.

Rated to handle up to 4.7 A of current at 655 V, the SSW-120-01-T-S model meets the needs of designers for reliable, high-density interconnection with through-hole termination. The orientation is vertical (straight), allowing it to interface smoothly with compatible male pin headers for both prototyping and production use.

Key technical attributes include its suitability for operating conditions from -55°C to 105°C, single row configuration, and compatibility with solder mounting techniques. The socket is part of the Samtec SSW series, known for supporting applications such as industrial control panels, automation modules, test equipment, and laboratory instrumentation, as well as a wide variety of electronic devices requiring compact connector solutions.

With its standardized contact pitch, durable materials, and proven electrical ratings, the Samtec SSW-120-01-T-S PCB socket serves as a dependable component for electronic OEMs, R&D labs, contract manufacturers, and repair operations involved in PCB assembly and modification.

Browse more PCB Sockets or discover other Samtec connection solutions in Electronics & Electricals on EnvMart.
