EOZ 16 Key Illuminated ABS Keypad IP67, Matrix Output, Yellow Housing, Polycarbonate Actuator IP67

EOZ IP67 16 Key Illuminated ABS Keypad IP67 is engineered for industrial and commercial electrical and automation systems, offering high-impact resistance with a yellow ABS housing and illuminated keys for easy operation under low light conditions.

This product features a 4 x 4 keypad layout with 16 keys outputting via a matrix design providing a compact and efficient solution for input devices used in industrial automation and control panels.

The keypad's mechanical durability is rated for four million operations per key, fabricated with polycarbonate actuator materials and a silver metal finish to withstand demanding usage.

Its IP67 rating certifies complete protection against dust ingress and resistance to water immersion, making it ideal for harsh environments such as outdoor or industrial waterproof control panels.

Operating temperature range from -25°C up to 85°C allows this keypad to perform reliably in extreme environments, suitable for HVAC, manufacturing, and electrical automation applications.

Contact resistance is kept low (≤200Ω) and dielectric strength is rated at 1500Vrms, ensuring safe electrical isolation and robust operation. This keypad mounts easily using either front or rear panel installation with a standard 0.1 inch pitch header for straightforward electrical integration.

It complies with RoHS environmental standards, providing assurance of safe and eco-friendly materials in manufacturing. Manufactured in France, this keypad is part of the EOZ S Series Lite Keypads and is perfect for industrial, automation, and electrical equipment requiring a reliable input device.

The keypad features 16 keys illuminated for clear visibility in low-light conditions. The housing is made of yellow ABS material ensuring robust protection and high impact resistance. Designed for full IP67 sealing, resistant to dust and water ingress for harsh environments.

Mechanical life per key supports up to four million operations ensuring long-term durability. Actuator keys feature silver polycarbonate material with a metal finish for enhanced strength. Operates reliably between -25°C to 85°C temperature range.

Contact rating supports low current applications at 5mA @ 5Vdc with low contact resistance. Front or rear panel mounting option with standard 0.1 inch pitch header connection. Compliant with RoHS standards ensuring environmentally safe manufacturing.
