Wurth Elektronik WR-TBL Series 4-Contact 3.81 mm Pitch 1 Row Pluggable Terminal Block 691348300004

Wurth Elektronik 691348300004 pluggable terminal block is a high-quality electronic connector designed for industrial and commercial electrical applications. This specific model belongs to the WR-TBL Series and features a 4-contact configuration with a 3.81 mm pitch and single-row vertical entry.

Constructed using durable Polyamide 66, the housing ensures stability and insulating properties, while the brass contacts provide reliable conductivity. The terminal block accommodates wire sizes from 0.05 mm² (30 AWG) up to 2.08 mm² (14 AWG), secured by M2 sized screws in a screw connection method, offering secure and maintenance-friendly wire termination.

The block maintains a current rating up to 8A and is rated for 1.6 kV AC withstanding voltage. Its compact dimensions (16.12 mm length, 11.1 mm width, 18.3 mm depth) make it well-suited for dense circuit board designs. It operates efficiently within a temperature range of -40°C to +115°C, ensuring durability in harsh environments.

Certified RoHS compliant and lead free, this terminal block meets environmental and safety standards, making it ideal for use in electronics, industrial automation, control systems, and power connectors. Its green housing color assists in visual identification during assembly and maintenance.

The terminal block supports a current rating of 8 amperes. It features a pitch spacing of 3.81 mm for compact PCB layouts. Constructed from polyamide 66 housing material for durability. Designed for wire sizes ranging from 0.05 mm² to 2.08 mm² (30 AWG to 14 AWG).

Incorporates screw wire connection method with M2 screw size for secure fastening. Green color coded for easy identification in electrical assemblies. Voltage rating of 1.6 kV AC ensuring high insulation performance. Compact dimensions: length 16.12 mm, width 11.1 mm, depth 18.3 mm.

Operates reliably in temperatures from -40°C to +115°C. Complies with RoHS standards and is lead free for environmental safety.

This Wurth Elektronik pluggable terminal block is suitable for applications in electronics manufacturing, industrial control panels, power distribution units, and various electronic devices requiring reliable and safe wire termination. Its versatility and adherence to international standards make it a dependable choice for engineers and technicians.

Explore more products from Wurth Elektronik or browse other Pluggable Terminal Blocks and connectors in the EnvMart catalog to find suitable components for your projects.
