Phoenix Contact SMSTB 2.5/3-ST-5.08 Series Pluggable Terminal Block, 3-Contact, 5.08 mm Pitch, 1 Row, 12A, 320V 1826296

Phoenix Contact 1826296 SMSTB 2.5/3-ST-5.08 series pluggable terminal block features a 3-contact configuration with a 5.08 mm pitch and one row, supporting various industrial and electronic electrical applications. It is designed with a polyamide housing material that provides excellent durability, insulation, and corrosion resistance.

Rated at 12A current and 320V voltage, this terminal block supports wire sizes ranging from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG) using screw connection with a tension sleeve, ensuring secure and stable wiring connections. The unit's straight orientation and female connector gender make it compatible with a wide array of electrical systems.

Optimized for tight installation situations, the terminal block enables operation and conductor connection from one direction, saving space and facilitating installation in compact environments. It permits connection of two conductors simultaneously, enhancing wiring flexibility and reducing component count on DIN rails.

The green colour coding helps in easy identification and wiring organisation. Manufactured in Germany with high standards, it assures reliable long-term performance. The product complies with RoHS directives, promoting environmental safety by restricting hazardous substances.

Durable polyamide housing ensures insulation and mechanical strength. Supports 0.2 to 2.5 mm² wire size with screw tension sleeve connection. Rated for 12A current and 320V voltage applications. Compact and optimized for tight installation spaces.

Enables connection of two conductors simultaneously. Standard 5.08 mm pitch and straight orientation. RoHS compliant and environmentally safe. High-quality manufacturing from Germany.

This terminal block is ideal for use in industrial automation, control gear, power distribution, and electronic component assemblies. It is widely used in manufacturing plants, electrical panels, HVAC systems, and other commercial and industrial electrical installations.

For professionals seeking reliable and standard-compliant terminal blocks, the Phoenix Contact SMSTB 2.5/3-ST-5.08 series provides a proven solution with excellent durability and performance.
