Weidmüller BL Series Pluggable Terminal Block, 3-Contact, 3.5 mm Pitch, 1 Row, 17A, 320V, Female Connector 1606650000

Weidmüller 1606650000 BL Series Pluggable Terminal Block is a precision-engineered electrical component designed for industrial and electronic applications requiring reliable and efficient wire termination. Featuring 3 contacts arranged in a single row with a 3.5 mm pitch, this terminal block supports a rated current of 17A and voltage up to 320V, making it suitable for medium power applications.

The female connector terminal utilizes a clamping yoke screw system that provides secure wire connections and simplifies installation, ensuring minimal maintenance. The housing is crafted from polybutylene terephthalate, a robust material known for excellent electrical insulation and mechanical toughness, finished in an orange color for easy identification.

With compatibility for wire sizes ranging from 28 AWG (0.28 mm²) to 14 AWG (1.4 mm²), and an orientation of 180°, this terminal block supports versatile wiring schemes. Dimensions are optimized for space-saving applications, measuring 18.5 mm in depth and 17.5 mm in width, fitting standard PCB layouts or mounting systems.

Manufactured in Germany, this product complies with quality and reliability standards, although it does not carry specific certifications. It belongs to the BL series known for outstanding connection technology in electrical assemblies.

The terminal block provides easy and secure wire termination through a clamping yoke screw mechanism. The female connector design supports straightforward mating and disconnection for maintenance. Compact 3.5 mm pitch allows dense packing in electronic circuits or control panels.

Compatible with wires from 28 AWG to 14 AWG ensuring flexibility for various conductor sizes. Housing made of polybutylene terephthalate ensures resistance to electrical and mechanical stresses. Rated for 17A and 320V allowing use in moderate current and voltage industrial environments.

Orange color housing facilitates quick visual identification within assemblies. Manufactured in Germany guaranteeing compliance with stringent industrial norms.

This pluggable terminal block is ideal for industrial automation systems, control panels, manufacturing equipment, and other applications requiring reliable and easy-to-maintain electrical connections. It provides a cost-effective and space-efficient solution as part of Weidmüller's Omnimate range, supporting vertical and horizontal header configurations.
