KEMET R75 Film Capacitor, 470 nF, ±5 %, Rated 160 V DC 90 V AC, Through Hole Mount R75GI34704000J
Specifications
| Country of Origin | India |
|---|---|
| Brand | KEMET |
| Height | 13.5mm |
| Length | 18mm |
| Model | R75GI34704000J |
| Packaging | Bag |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | R75 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±5 % |
| Capacitance | 470nF |
| Minimum Operating Temperature | -55°C |
| Dissipation Factor | 0.05% |
| Lead Length | 30mm |
| Standards/Approvals | RoHS, IEC 60286-2 |
| Pin Count | 2 |
| Rated AC Voltage | 90V ac |
| Rated DC Voltage | 160V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q100 |
Key Features
- Constructed from metallized polypropylene film ensuring excellent performance.
- Radial leads with 15 mm pitch and 0.8 mm diameter for secure PCB mounting.
- Designed for high-frequency applications with a dissipation factor of 0.05%.
- Operating temperature range from -55°C to 105°C for reliable operation under varying conditions.
- Encapsulated in self-extinguishing material compliant with UL94V-0 standard for safety.
- Suitable for use in deflection circuits, electronic ballasts, power factor correction, and switched mode power supplies.
- Packaged in bags for convenient handling and inventory.
- Automotive standard compliant (AEC-Q100), ensuring robustness in demanding environments.
Product Description
KEMET R75GI34704000J film capacitor is a high-quality metallized polypropylene film capacitor featuring a capacitance of 470 nF with a tolerance of ±5 % and a rated DC voltage of 160 V along with an AC voltage rating of 90 V. The capacitor employs through hole mounting with radial leads designed for secure soldering on printed circuit boards.
This capacitor exhibits exceptional high-frequency performance thanks to its low dissipation factor of 0.05%. Its lead pitch measures 15 mm with a lead diameter of 0.8 mm and lead length of 30 mm. The physical dimensions include a height of 13.5 mm, length of 18 mm, and width of 7.5 mm, making it compact and space-efficient.
Safe and reliable in various industrial and electronic applications, this capacitor meets automotive standard AEC-Q100, RoHS compliance, and IEC 60286-2 standards. It operates smoothly within a broad temperature range of -55°C to 105°C and is encapsulated in a self-extinguishing material to meet UL94V-0 safety requirements.
Common applications include deflection circuits in televisions (S-correction), resonant capacitors in electronic ballasts and compact lamps, power factor correction, coupling capacitors in switched mode power supplies (SMPS), timing, and oscillator circuits. Note that it is not suitable for across-the-line applications.
Constructed from metallized polypropylene film with radial tinned wire leads. Wide voltage range from 160 V DC up to 2,000 V DC across R75 series. Designed for high-frequency and automotive-grade applications. Encapsulated in flame-retardant material meeting UL94V-0.
Reliable over extended temperature ranges of -55°C to 105°C. Complies with stringent automotive and industry standards. Provided in bag packaging for ease of use and storage. Ideal for electronic ballast, power factor correction, and oscillator circuits.
This KEMET Film Capacitor is suitable for industrial, electronic manufacturing, automotive electronics, and laboratory applications requiring high precision and durability. Browse EnvMart’s electronics components catalog to explore more capacitors and related passive components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 470 nF with a tolerance of ±5%.
It has a rated DC voltage of 160 V and an AC voltage rating of 90 V.
The operating temperature range is from -55°C to 105°C.
The dissipation factor is 0.05%, indicating its suitability for high-frequency applications.
The dimensions are 13.5 mm in height, 18 mm in length, and 7.5 mm in width.
It is packaged in bags for convenient handling and inventory.
This model uses through hole mounting with radial leads.
It complies with RoHS, IEC 60286-2 standards, and is automotive standard compliant (AEC-Q100).
The lead pitch is 15 mm, and the lead diameter is 0.8 mm.
It is suitable for applications such as deflection circuits, electronic ballasts, power factor correction, and switched mode power supplies.
The lead length is 30 mm, allowing for secure soldering on printed circuit boards.
The country of origin for this capacitor is India.
