KEMET R76UI118050H4J R76_125C Film Capacitor 1.8 nF ±5% 2 kV DC 700 V AC Through Hole

KEMET R76UI118050H4J is a film capacitor from the R76_125C series featuring a capacitance of 1.8 nF with ±5% tolerance. It is rated for 2 kV DC and 700 V AC voltages, suitable for demanding electrical applications requiring high voltage stability and reliability. This through-hole mounted capacitor offers an automotive-grade AEC-Q200 standard compliance and is encased in a durable, self-extinguishing plastic housing ensuring safety and durability.

The capacitor uses polypropylene film and double metallized polyester film electrodes to provide superior electrical characteristics. Radial tinned wire leads are welded to the metal layers, ensuring strong electrical connection and mechanical stability. Its operating temperature range spans from -55°C to 125°C, allowing use in harsh industrial and automotive environments.

This capacitor features a 15 mm lead pitch and 25 mm lead length, making it compatible with standard through-hole PCB layouts. With a low dissipation factor of 0.1% and equivalent series resistance (ESR) of 354 mΩ, it delivers excellent performance in high frequency and snubber circuits.

Typical applications include resonant circuits, high-frequency current handling, snubber circuits, and silicon-controlled rectifier (SCR), IGBT, and MOSFET commutation circuits, especially in conditions involving high voltage, high current, and high ambient temperatures.

The capacitor complies with IEC 60286-2 standards and is RoHS certified. Packaged in bags, this component is manufactured in China, reflecting KEMET's quality assurance and international compliance standards.

Constructed with polypropylene and double metallized polyester film for reliable capacitance stability. Encapsulated in a self-extinguishing plastic case for enhanced safety. Automotive grade compliant with AEC-Q200 standard.

Capacitance tolerance of ±5% ensuring precise electrical characteristics. Supports a wide temperature range from -55°C to +125°C for versatile industrial use. Low dissipation factor and ESR contribute to efficient high-frequency circuit performance.

Through-hole mounting with 15 mm lead pitch and solder terminal type for easy integration. Meets IEC 60286-2 and RoHS standards for quality and environmental compliance. Explore our Electronics & Electricals catalogue for more Film Capacitors and electronic components to meet your industrial and design requirements.
