TRACOPOWER Regulated Isolated DC/DC Converter 5V DC 400mA 5.5V DC Input 4.5V Input 2W Through Hole DIP Package THI 0511
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THI DC/DC Converter, 5V dc/ 400 mA, 5 |
| Brand | TRACOPOWER |
| Efficiency | 62% |
| Length | 32mm |
| Model | THI 0511 |
| Depth | 10mm |
| Mount Type | Through Hole |
| Series | THI |
| Maximum Operating Temperature | 75°C |
| Package Type | DIP |
| Minimum Operating Temperature | -25°C |
| MTBF | 600000h |
| Number of outputs | 1 |
| Maximum Output Power | 2W |
| Maximum Input Voltage | 5.5V dc |
| Minimum Input Voltage | 4.5V |
| Number of Pins | 24 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 400mA |
| Isolation Voltage | 2.5kV dc |
Key Features
- The DC/DC converter features high isolation voltage of 2.5kV DC ensuring safety and reliability.
- Its efficiency of 62% supports efficient power conversion in industrial and medical applications.
- The converter operates in harsh environments with a temperature range from -25 °C up to 75 °C.
- The device offers a mean time between failures (MTBF) of 600000 hours for long operational life.
- It includes short circuit protection and a 24-pin DIP plastic package measuring 32mm x 20mm x 10mm for easy PCB integration.
- The product is compliant with medical and industrial safety standards including EN 60950, IEC 60950, IEC 60601, and EN 60601-1.
- Designed for regulated isolated power supply needs in electronic, medical, and industrial control equipment.
Product Description
TRACOPOWER THI 0511 is a high-performance regulated isolated DC/DC converter delivering 5V DC output at 400mA with a maximum output power of 2W. It operates with an input voltage range of 4.5V to 5.5V DC and is built as a through-hole DIP package suitable for compact printed circuit board designs.
The converter features a robust isolation voltage of 2.5kV DC along with supplementary insulation allowing it to handle working voltages up to 250Vac. This makes it particularly suitable for medical applications and industrial controls where high safety and reliability standards are required.
With an efficiency rating of 62%, this converter balances power savings and thermal management. It operates reliably over a wide temperature range from -25°C to 75°C and includes short circuit protection to prevent damage during fault conditions.
The 24-pin DIP package is plastic mold UL 94V-0 rated, measuring 32mm length, 20mm width, and 10mm depth, supporting easy implementation in various electronic assemblies. The design adheres to international standards such as EN 60950, IEC 60950, IEC 60601, and EN 60601-1, making it compliant for use in medical-grade equipment.
This product is ideal for powering sensitive electronics requiring regulated isolated voltage outputs, commonly used in industrial, medical, laboratory, and automation equipment. The high MTBF of 600000 hours ensures longevity and dependable service life for critical applications.
The DC/DC converter features high isolation voltage of 2.5kV DC ensuring safety and reliability. Its efficiency of 62% supports efficient power conversion in industrial and medical applications. The converter operates in harsh environments with a temperature range from -25 °C up to 75 °C.
The device offers a mean time between failures (MTBF) of 600000 hours for long operational life. It includes short circuit protection and a 24-pin DIP plastic package measuring 32mm x 20mm x 10mm for easy PCB integration.
The product is compliant with medical and industrial safety standards including EN 60950, IEC 60950, IEC 60601, and EN 60601-1. Designed for regulated isolated power supply needs in electronic, medical, and industrial control equipment.
Explore our range of DC/DC Converters at EnvMart for reliable power supply solutions in diverse industrial and medical applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The converter provides an output voltage of 5V DC and an output current of 400mA.
It operates with an input voltage range of 4.5V to 5.5V DC.
The maximum output power of this model is 2W.
It features a high isolation voltage of 2.5kV DC.
The DIP package measures 32mm in length, 20mm in width, and 10mm in depth.
The efficiency of this model is rated at 62%.
It operates reliably over a temperature range from -25°C to 75°C.
The mean time between failures (MTBF) is 600000 hours.
This model is designed for through-hole mounting.
It is compliant with several safety standards including EN 60950, IEC 60950, IEC 60601, and EN 60601-1.
This converter is designed for use in electronic, medical, and industrial control equipment requiring regulated isolated power supply.
This model has one output.
