Omron PCB Power Relay 24V DC Coil 10A Switching Current SPST G5Q-1A DC24 (TY)

Omron G5Q-1A DC24 (TY) PCB Power Relay is a compact, high-performance relay designed for PCB mounting. It features a 24V DC coil and a single pole single throw (SPST) contact configuration with a 10A switching current capability, making it suitable for a variety of industrial and commercial electrical applications.

The relay's dimensions are 20.3mm in length, 15.8mm in height, and 10.3mm in width, allowing integration in space-constrained environments. It offers a high isolation voltage of 8 kV between coil and contacts, ensuring electrical safety and robustness against surges.

Constructed with silver alloy contacts, the relay guarantees high reliability and minimal contact resistance during switching operations. Its coil resistance is 2.9 kΩ with a coil power consumption of 4 kW, optimizing power usage in control circuits.

Operating temperature ranges from -40°C to 85°C makes this relay adaptable for harsh industrial environments. The relay supports switching AC voltages up to 400V and switching power rating up to 1.25 kVA, enabling its use in various power relay functions within automation and control systems.

Mounting is via PCB with solder terminal type connections, facilitating easy assembly on printed circuit boards. The product complies with UL, RoHS, IEC, EN, and CE standards, assuring quality and regulatory compliance.

This relay is ideal for applications in electrical, industrial automation, manufacturing control, HVAC systems, and other environments requiring reliable switching of moderate power loads.

Explore more Power Relay solutions and Omron products on EnvMart to meet your industrial relay application needs. The G5Q series offers compact size with dimensions 20.3mm length, 15.8mm height, and 10.3mm width. It provides high isolation between coil and contacts withstanding 8 kV surge voltage.

The relay uses silver alloy contact material ensuring reliable switching performance. Operates within a temperature range from -40°C to 85°C for wide environmental use. The coil resistance is 2.9 kΩ with a coil power rating of 4 kW.

Designed for PCB mount with solder terminal type to fit standard printed circuit boards. Supports switching AC voltage up to 400V and switching power of 1.25 kVA. Meets multiple standards and approvals including UL, RoHS, IEC, EN, and CE.
