TRACOPOWER 3.5 Watt Surface Mount DC/DC Converter 24V DC Output 146 mA Input 9-18V TIM 3.5-1215SM
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TRACOPOWER |
| Efficiency | 82% |
| Length | 24.3mm |
| Model | TIM 3.5-1215SM |
| Depth | 10.5mm |
| Width | 14.4mm |
| Mount Type | Surface |
| Series | TIM 3.5 |
| Maximum Operating Temperature | 90°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| MTBF | 5040000h |
| Number of outputs | 1 |
| Maximum Output Power | 3.5W |
| Maximum Input Voltage | 18V dc |
| Minimum Input Voltage | 9V |
| Number of Pins | 16 |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 146mA |
| Isolation Voltage | 5kV ac |
| Input Ratio | 1:12 |
| Input Ratio1 | 12 |
Key Features
- Compact surface mount package with 16 pins for easy PCB integration.
- Supports wide input voltage range from 9V to 18V DC to adapt to various power sources.
- Output voltage stabilized at 24V DC with low ripple and noise.
- High isolation voltage of 5000 VAC enhances safety and reliability.
- Operating temperature range from -40°C to 90°C suitable for harsh industrial environments.
- Provides efficiency up to 82% minimizing energy loss.
- Compliance with IEC/ES 60601-1 3rd edition for medical reinforced I/O isolation.
- Low leakage current and built-in input filter meeting EN55022 Class A standards.
Product Description
TRACOPOWER TIM 3.5-1215SM is a high-quality 3.5 watt DC/DC converter designed for industrial and medical electronic applications requiring reliable voltage conversion and isolation.
This surface mount device provides a regulated 24V DC output at 146 mA from input voltages of 9V to 18V DC, accommodating a broad range of power sources with a 1:12 input to output ratio.
The converter offers robust electrical isolation of 5000 VACrms, certified to IEC/ES 60601-1 3rd edition, making it suitable for reinforced I/O isolation in medical equipment and sensitive industrial systems.
With a compact footprint measuring 24.3 mm in length, 14.4 mm width, and 10.5 mm depth, it fits easily onto printed circuit boards via its 16-pin surface mount package. Operating across temperatures from -40°C to 90°C, this model withstands demanding environments while maintaining an efficiency of 82%, reducing energy losses and heat generation.
The converter features low leakage current and integrated input filters compliant with EN55022 Class A electromagnetic compatibility standards, ensuring minimal interference in signal sensitive applications.
Typical applications include industrial automation, medical equipment power supplies, communications, and instrumentation systems where stable isolated power is critical. Compact surface mount package with 16 pins for easy PCB integration.
Supports wide input voltage range from 9V to 18V DC to adapt to various power sources. Output voltage stabilized at 24V DC with low ripple and noise. High isolation voltage of 5000 VAC enhances safety and reliability. Operating temperature range from -40°C to 90°C suitable for harsh industrial environments.
Provides efficiency up to 82% minimizing energy loss. Compliance with IEC/ES 60601-1 3rd edition for medical reinforced I/O isolation. Low leakage current and built-in input filter meeting EN55022 Class A standards. Long MTBF of approximately 5,040,000 hours ensures extended reliability.
Choose TRACOPOWER TIM 3.5-1215SM for reliable, efficient, and safe DC/DC power conversion in diverse industrial and medical electronics applications. Browse EnvMart’s range of DC/DC Converters for compatible solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The output voltage of this model is stabilized at 24V DC.
It supports a wide input voltage range from 9V to 18V DC.
The maximum output power is 3.5 watts.
It has a high isolation voltage of 5000 VAC, enhancing safety and reliability.
The dimensions are 24.3 mm in length, 14.4 mm in width, and 10.5 mm in depth.
It provides an efficiency of up to 82%, minimizing energy loss.
The operating temperature range is from -40°C to 90°C, suitable for harsh environments.
This model has one output.
It complies with IEC/ES 60601-1 3rd edition for medical reinforced I/O isolation.
The mean time between failures (MTBF) is approximately 5,040,000 hours.
It uses a surface mount type with 16 pins for easy PCB integration.
It is suitable for industrial automation, medical equipment power supplies, communications, and instrumentation systems.
