Vishay DC Input Optocoupler Surface Mount 4-Pin Phototransistor 60mA 5300V ac Isolation SFH6156-2X001T

Vishay SFH6156-2X001T DC Input Optocoupler is a high-performance optocoupler featuring a 4-pin surface mount package. It provides phototransistor output and is designed for isolating electrical signals in various electronics applications. The device supports a maximum forward voltage of 1.65 V and can handle input currents up to 60 mA.

This optocoupler offers exceptional voltage isolation of 5300 V ac, making it ideal for use in industrial controls, telecommunication systems, switch mode power supplies, and programmable logic controllers. It is capable of operating reliably in temperatures ranging from -55°C to 100°C, thus suitable for demanding environments.

The SFH6156-2X001T features fast switching with a typical rise time of 3 microseconds and a fall time of 14 microseconds. It is packaged in tape and reel form, facilitating efficient insertion into automated assembly lines.

Conforming to EN, IEC, and UL standards, this optocoupler ensures compliance with safety and quality benchmarks.

Applications include isolation in AC adapters, smart meters, industrial automation, and office equipment power management. Its robust design supports long-term performance in diverse electronic and electrical equipment.

Designed for DC input with phototransistor output for electrical isolation. Maximum forward voltage of 1.65 V for efficient operation. High isolation voltage rating of 5300 V ac for safety. Operating temperature range from -55°C to 100°C.

Typical rise time of 3 μs and fall time of 14 μs for fast response. Package supplied as tape and reel for ease of automated mounting. Complies with EN, IEC, and UL standards for quality assurance. Explore the Electronics Components category at EnvMart for more Optocouplers and photodetectors to meet your project requirements.
