Honeywell Technologies HSC Series Differential Pressure Sensor Board 6-Pin DIP 3.3V to 5V Supply ±0.25% HSCDRRD005NDAA5

Honeywell Technologies HSCDRRD005NDAA5 is a differential pressure sensor board featuring a 6-pin DIP package designed for precise measurement of pressure differences between two ports. It operates reliably from a minimum supply voltage of 3.3V up to 5V and provides ratiometric analogue or digital outputs. The sensor delivers ±0.25% full-scale accuracy which reduces the frequency and complexity of calibration in industrial and commercial applications.

Its dual radial barbed ports facilitate straightforward connections to fluidic systems, while the onboard signal conditioning and temperature compensation from 0°C to 50°C ensure stable and calibrated pressure output. The sensor module has a compact footprint with dimensions of 13.75mm height, 13.3mm width, and 10mm length, making it suitable for board-mount installations where space is constrained.

This device is intended primarily for dry, non-corrosive gases such as air, making it ideal for HVAC differential pressure monitoring, filter detection, medical respiratory flow and ventilator systems, as well as in flow instrumentation and gas chromatography equipment. Its robust mechanical design complies with IPC/JEDEC J-STD-020E moisture sensitivity level 1 for reflow soldering processes and meets ISO 9001 automotive standards.

The operating temperature range extends from -20°C to +85°C, enabling use in diverse environmental and industrial contexts. With low power consumption under 10mW, it is also effective for battery-powered applications. The sensor’s rapid output update rates of approximately 1 kHz (analogue) and 2 kHz (digital) improve responsiveness in dynamic measurement scenarios.

±0.25% full-scale accuracy reduces calibration effort. Operates from 3.3V or 5V single supply voltage. Dual radial barbed ports for easy fluidic connections. Temperature compensated 0°C to 50°C for stable output. Compact 6-pin DIP, board-mount package.

Suitable for HVAC, medical, flow instrumentation, and environmental sensing. Compliant with IPC/JEDEC J-STD-020E and ISO 9001 automotive standards. Operating temperature range -20°C to +85°C. Low power consumption under 10mW for battery use.

This product is a part of the Honeywell HSC series and is engineered for precise, rapid differential pressure measurements in industrial, laboratory, HVAC, medical, and environmental monitoring applications. Explore more Honeywell pressure sensors and related components on EnvMart’s dedicated category pages.
