Vishay Single Layer Ceramic Capacitor 20 nF 3.5kV dc Y5U Dielectric Screw Mount Disc 715C10DKS20
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 3.5kV dc |
| Diameter | 54.1mm |
| Brand | Vishay |
| Height | 19.8mm |
| Model | 715C10DKS20 |
| Packaging | Bulk |
| Mount Type | Screw |
| Series | 715C10DK |
| Maximum Operating Temperature | 85°C |
| Tolerance | -20 to 80 % |
| Capacitance | 20nF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Dissipation Factor | 0.02% |
| Standards/Approvals | RoHS |
| Package/Case | Disc |
| Pin Count | 2 |
| Dielectric | Y5U |
| Suppression Class | Class II |
Key Features
- Capacitance of 20 nanofarads ensuring stable electrical performance.
- Rated for high voltage operation up to 3.5kV DC.
- Uses Y5U dielectric material with tolerance range of -20% to +80%.
- Designed with screw terminal mount for secure installation.
- Disc package type with diameter of 54.1 mm and height of 19.8 mm.
- Operating temperature range from -30°C to +85°C.
- Compliant with RoHS standards for environmental safety.
- Low dissipation factor of 0.02% for efficient energy use.
Product Description
Vishay 715C10DKS20 Single Layer Ceramic Capacitor is a high voltage Class 2 ceramic DC disc capacitor designed for demanding industrial and electronic applications. With a capacitance of 20 nF and a DC voltage rating of 3.5 kV, it offers reliable performance in high voltage power supplies, CO2 laser systems, and medical X-ray equipment where durability and insulation resistance are critical.
This capacitor features a Y5U dielectric providing a tolerance of -20% to +80%, suitable for applications requiring flexible voltage handling. The device mounts via screw terminals secured in a disc-shaped package measuring 54.1 mm in diameter and 19.8 mm in height, ensuring robust mechanical stability.
Operating temperature ranges from -30°C to 85°C, making it appropriate for industrial, laboratory, and commercial environments. The low dissipation factor of 0.02% minimizes energy loss, improving efficiency. Additionally, it complies with RoHS environmental standards, supporting sustainable manufacturing practices.
20 nF capacitance for stable electrical characteristics. 3.5 kV DC voltage rating for high voltage operation. Y5U dielectric with wide tolerance range. Screw terminal mount ensuring secure installation. Disc shaped package: 54.1 mm diameter, 19.8 mm height.
Operating temperature: -30°C to 85°C. RoHS compliant for environmental safety. Low dissipation factor of 0.02%. High voltage power supplies, CO2 lasers, X-ray equipment.
This product is manufactured in Germany with quality assurance from Vishay. It is ideal for electronics engineers, prototyping, and advanced industrial uses. Browse related capacitors and components on EnvMart for comprehensive electronic design solutions.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 20 nanofarads (nF).
It is rated for a maximum DC voltage of 3.5 kV.
This unit uses a Y5U dielectric material, which has a tolerance range of -20% to +80%.
The capacitor has a diameter of 54.1 mm and a height of 19.8 mm.
It operates within a temperature range of -30°C to +85°C.
It features a screw terminal mount for secure installation.
The dissipation factor is 0.02%, which contributes to efficient energy use.
Yes, it complies with RoHS standards for environmental safety.
This capacitor is manufactured in Germany.
It is suitable for high voltage power supplies, CO2 laser systems, and medical X-ray equipment.
This model has a pin count of 2.
The capacitor is packaged in bulk.
