Vishay Single Layer Ceramic Capacitor 560 pF 34kV DC ±20% N4700 Dielectric Moulded Epoxy Screw Terminal 85°C 715C50KTT56M5
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 34kV dc |
| Diameter | 37mm |
| Brand | Vishay |
| Height | 35mm |
| Model | 715C50KTT56M5 |
| Packaging | Bulk |
| Mount Type | Screw |
| Series | 715C50KT |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±20 % |
| Capacitance | 560pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Dissipation Factor | 0.2% |
| Standards/Approvals | RoHS |
| Package/Case | Moulded Epoxy |
| Dielectric | N4700 |
| Suppression Class | Class I |
Key Features
- This capacitor features a moulded epoxy package with screw terminal mounting for secure connections.
- It has a maximum operating temperature of 85°C and a minimum of -30°C suitable for demanding environments.
- The device exhibits a low dissipation factor of 0.2% at 1 kHz ensuring minimal energy loss.
- Its Class I suppression and N4700 strontium-based ceramic dielectric provide excellent stability and negligible piezoelectric effects.
- Designed for high voltage AC and DC use, ideal for power supplies, CO2 lasers, and X-ray equipment.
- The capacitor is RoHS compliant and manufactured in Germany ensuring quality and environmental standards.
Product Description
Vishay 715C50KTT56M5 Single Layer Ceramic Capacitor is engineered for high voltage applications demanding reliability and stability. Featuring a 560 pF capacitance rating with a tolerance of ±20%, it operates at a high voltage of 34kV DC with a screw-mounted terminal design for robust mechanical and electrical connection.
The capacitor employs a Class I N4700 dielectric ceramic material, strontium-based, which ensures negligible electrostrictive and piezoelectric effects, resulting in excellent performance stability. Its moulded epoxy case provides protection and insulation, allowing operation in temperatures from -30°C up to 85°C.
With a low dissipation factor of 0.2% measured at 1 kHz, energy losses are minimal, making this component suitable for sensitive electronics and power supply designs. Its construction supports high voltage AC and DC applications including usage in CO2 laser systems, X-ray apparatus, and various industrial high voltage power supplies.
Manufactured in Germany under RoHS compliance, this capacitor meets rigorous standards ensuring durability and environmental safety. The screw terminal mounting facilitates easy and secure installation in circuit assemblies.
This capacitor features a moulded epoxy package with screw terminal mounting for secure connections. It has a maximum operating temperature of 85°C and a minimum of -30°C suitable for demanding environments. The device exhibits a low dissipation factor of 0.2% at 1 kHz ensuring minimal energy loss.
Its Class I suppression and N4700 strontium-based ceramic dielectric provide excellent stability and negligible piezoelectric effects. Designed for high voltage AC and DC use, ideal for power supplies, CO2 lasers, and X-ray equipment.
The capacitor is RoHS compliant and manufactured in Germany ensuring quality and environmental standards. Explore more electronic components like capacitors and discover solutions for industrial, medical, laboratory, and manufacturing applications at EnvMart.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 560 pF with a tolerance of ±20%.
It has a maximum voltage rating of 34 kV DC, making it suitable for high voltage applications.
This unit operates within a temperature range of -30°C to 85°C.
It employs an N4700 strontium-based ceramic dielectric, which provides excellent stability and negligible piezoelectric effects.
It features a screw terminal mounting type for secure connections in circuit assemblies.
The dissipation factor is 0.2% at 1 kHz, ensuring minimal energy loss during operation.
The capacitor has a diameter of 37 mm and a height of 35 mm.
It features a moulded epoxy package that provides protection and insulation.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
This capacitor is manufactured in Germany, ensuring quality and adherence to standards.
The series name of this capacitor is 715C50KT.
