Crydom GN3 Series Solid State Relay Panel Mount 25A Load, 600 V AC Load, 32V DC Control GN325DSZ

Crydom GN325DSZ is a GN3 Series Solid State Relay designed for controlling AC loads with high efficiency and durability. This panel mount relay supports a maximum load current of 25 A and a maximum load voltage of 600 V AC, making it suitable for industrial automation and control applications.

The relay operates with a control voltage ranging from 4 V DC to 32 V DC and features zero cross switching functionality, which minimizes electrical noise and stress on connected loads.

Equipped with screw terminal connections, the GN325DSZ ensures a secure and reliable installation. Its epoxy-free design reduces internal stresses, while the DBC substrate provides superior thermal performance for extended relay lifespan.

Capacitance of 8 pF and a low off-state leakage current of 0.06 mArms contribute to its precise and efficient operation. The relay withstands operating temperatures from -40°C up to 80°C, suitable for harsh industrial environments.

It complies with various industry standards including CE, CSA LR 38595, cULus recognized, EN 60950-1, multiple IEC standards, TUV, and UL 94 V-0, ensuring safety and reliability in demanding applications.

The relay is ideal for use in industrial control panels, HVAC systems, manufacturing equipment, and automation processes where robust and reliable switching is critical. This solid state relay includes a snubber circuit and internal TVS diode to protect against voltage spikes.

Back-to-back dual SCR output supports heavy industrial loads without external transient protection. Designed for a high endurance rating of 100k cycles under UL508 standards. The panel mount format facilitates easy integration into electrical control panels.

Epoxy-free construction enhances performance reliability under thermal cycling.

Engineered for demanding industrial applications, the Crydom GN325DSZ solid state relay provides a reliable switching solution for controlling various AC loads with enhanced thermal management and safety features. Explore EnvMart's extensive range of Solid State Relays to find the best component for your control system needs.
