STMicroelectronics Low Power Rail-to-Rail Output 36 V Operational Amplifier 560 kHz Gain Bandwidth Product 5-Pin TSB611ILT
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3mm |
| Model | TSB611ILT |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | TSB611 |
| Output Current | 70mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 2.7V |
| GBP - Gain Bandwidth Product | 560kHz |
| Input Bias Current | 15 nA |
| Vos - Input Offset Voltage | 1.6 mV |
| Slew Rate | 0.2V/μs |
| Input Offset Current | 20 nA |
| Gain bandwidth product | 560 kHz typical |
| Low offset voltage | 1 mV max |
Key Features
- Low offset voltage of 1 mV maximum ensures precise signal amplification.
- Typical gain bandwidth product of 560 kHz provides reliable frequency response.
- Operating supply voltage range from 2.7 V to 36 V supports versatile applications.
- Low power consumption of 125 μA maximum at 36 V enhances energy efficiency.
- Compact 5-pin SOT-23 package facilitates surface mount PCB integration.
- Input bias current of 15 nA and input offset current of 20 nA enable sensitive signal handling.
- High output current capability of up to 70 mA suits driving loads effectively.
- Wide operating temperature range from -40°C to 125°C supports harsh environments.
Product Description
The STMicroelectronics TSB611ILT operational amplifier is designed for low power consumption and rail-to-rail output operation across a wide supply voltage range from 2.7 V to 36 V. This device is engineered to provide stable and accurate signal amplification with a typical gain bandwidth product of 560 kHz and a maximum offset voltage of only 1 mV.
Housed in a compact 5-pin SOT-23 surface mount package measuring just 3 mm in length, 1.75 mm in width, and 1.3 mm in height, the TSB611ILT is optimized for space-constrained designs. Its low input bias current of 15 nA and low input offset current of 20 nA make it suitable for precision analog circuits requiring sensitive signal processing.
The operational amplifier delivers up to 70 mA output current, making it capable of driving a wide range of loads. With a slew rate of 0.2 V/μs and a maximum operating temperature of 125°C, this amplifier can be deployed in demanding industrial, automotive, and consumer electronics applications.
This amplifier complies with the RoHS directive and meets the stringent Automotive AEC-Q100 standard, ensuring reliable performance in automotive environments. Manufactured in Malaysia, it reflects stringent quality and production standards.
Low offset voltage of 1 mV maximum ensures precise amplification for sensitive electronic circuits. Wide supply voltage operation from 2.7 V to 36 V supports diverse system requirements. Low current consumption of 125 μA maximizes energy efficiency in battery-powered devices.
Compact SOT-23 package allows for high-density PCB layouts in compact electronics. Input bias and offset currents minimize signal errors in precision applications. Automotive grade qualification provides confidence for use in vehicle systems.
Suitable for industrial instrumentation, audio amplification, and sensor signal conditioning.
Explore more Operational Amplifiers and semiconductor products in our Electronics & Electricals category at EnvMart for high-quality components suited for design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TSB611ILT operates within a supply voltage range from 2.7 V to 36 V, making it suitable for various applications.
This operational amplifier has a typical gain bandwidth product of 560 kHz, ensuring reliable frequency response for signal amplification.
It can deliver an output current of up to 70 mA, allowing it to effectively drive a range of loads.
The SOT-23 package measures 3 mm in length, 1.75 mm in width, and 1.3 mm in height, facilitating compact PCB integration.
The maximum operating temperature for the TSB611ILT is 125°C, allowing it to function in demanding environments.
This model features a low input bias current of 15 nA, which is beneficial for sensitive signal handling.
The operational amplifier has a maximum input offset voltage of 1 mV, ensuring precise signal amplification.
The TSB611ILT complies with the AEC-Q100 automotive standard, indicating its suitability for automotive applications.
It has a slew rate of 0.2 V/μs, which is important for determining how quickly the output can respond to changes in input.
The minimum operating temperature for this operational amplifier is -40°C, allowing it to operate in harsh conditions.
The TSB611ILT is designed for surface mount installation, which is ideal for high-density PCB layouts.
This operational amplifier complies with the RoHS directive, ensuring it meets environmental safety standards.
