Omron Subminiature Pin Plunger Micro Switch Through Hole Terminal 5A 250V AC 30V DC SS-5-3D

Omron SS-5-3D is a subminiature pin plunger micro switch featuring a through hole terminal design, rated for 5A current at 250V AC and 30V DC. This robust micro switch is designed for precise mechanical switching in a compact footprint, making it suitable for applications requiring reliable and frequent actuation.

The switch employs a pin plunger actuator type, providing dependable tactile feedback with an operating force of 1.47N. Its contact configuration is SPST (single pole single throw) facilitating simple on/off control. The IP40 rating offers protection against ingress of solid particles larger than 1 millimeter, making it fit for indoor and controlled environments.

With a mechanical life rated at 30 million operations, the SS-5-3D ensures long-lasting performance and reliability, minimizing maintenance and replacement needs in industrial automation and control circuits. It operates efficiently within a temperature range from -25°C up to 85°C, accommodating a broad spectrum of environmental conditions.

This micro switch complies with RoHS directives, ensuring environmentally responsible manufacturing standards. Its terminal style is through hole, suitable for soldering onto printed circuit boards or integrating into various electronic assemblies.

The Omron SS series is known for its stable two split spring mechanism to enhance operational stability and longevity. Available with multiple operating forces, this SS-5-3D model balances sensitivity and durability, making it ideal for applications in electrical appliances, industrial machinery, instrumentation, and HVAC controls.

Features a pin plunger actuator for precise mechanical control. Supports a switch contact current of 5 amperes for moderate power applications. Contact configuration is single pole single throw (SPST) for basic switching functions.

IP40 rated for protection against solid objects greater than 1mm. Mechanical life expectancy of 30 million operations ensures longevity. Operating force is low at 1.47 newtons for easy actuation. Compatible with operating temperatures from -25°C to 85°C.

RoHS compliant to meet environmental standards. Through hole terminal type for versatile PCB mounting.

This product is ideal for electrical and industrial applications requiring a compact, reliable switch with precise actuation and extended service life. Explore more Micro Switches and automation components with Omron at EnvMart.
