Panasonic PCB Power Relay 24V DC Coil 10A Switching Current DPDT Contact Configuration ADJ54024
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 16.5mm |
| Length | 29mm |
| Model | ADJ54024 |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | Through Hole |
| Typical Applications | Brake circuits, motor control, time switches |
| Standards/Approvals | TUV, UL, RoHS, IEC, VDE, CE |
| Coil Resistance | 2304Ω |
| Coil Voltage | 24V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 250mW |
Key Features
- This relay is PCB mounting type with a compact size of 29 x 13 x 16.5 mm.
- It supports up to 250V AC switching voltage and has a switching power of 4kVA.
- The coil power consumption is low at 250mW making it energy efficient.
- It uses gold-plated contacts for reliable and durable electrical connections.
- Operating temperature ranges from -40°C to 70°C, suitable for industrial environments.
- Terminal type is through-hole ensuring secure PCB mounting.
- Standards compliance includes TUV, UL, RoHS, IEC, VDE, and CE certifications.
- Typical applications include brake circuits, motor control circuits, and time switches.
Product Description
Panasonic ADJ54024 is a high-quality PCB Power Relay designed for industrial, automation, and electrical use. It operates on a 24V DC coil voltage with a contact configuration of Double Pole Double Throw (DPDT) to handle multiple switching tasks effectively. The relay supports a switching current of 10A and can manage AC switching voltages up to 250V with a power rating of 4kVA.
The relay’s compact dimensions (29mm length, 13mm width, and 16.5mm height) make it ideal for integration into compact PCBs. It has gold-plated contacts to ensure excellent conductivity and durability over extended operating periods. With an operating temperature range from -40°C up to 70°C, it is suitable for a wide range of industrial and commercial applications.
Its coil power consumption is very low at just 250mW, which contributes to energy efficiency in circuit design. The through-hole terminal type offers reliable mounting on printed circuit boards. Panasonic ADJ series relays feature high insulation and power latching capabilities making them robust and versatile components.
This relay finds typical use in brake circuits, motor control systems, and time switch applications in factory automation, household appliance networks, and various electric power devices. It complies with international safety and environmental standards including TUV, UL, RoHS, IEC, VDE, and CE, ensuring reliable and compliant performance.
This relay is PCB mounting type with a compact size of 29 x 13 x 16.5 mm. It supports up to 250V AC switching voltage and has a switching power of 4kVA. The coil power consumption is low at 250mW making it energy efficient.
It uses gold-plated contacts for reliable and durable electrical connections. Operating temperature ranges from -40°C to 70°C, suitable for industrial environments. Terminal type is through-hole ensuring secure PCB mounting.
Standards compliance includes TUV, UL, RoHS, IEC, VDE, and CE certifications. Typical applications include brake circuits, motor control circuits, and time switches. Explore further Panasonic Signal Relays and electrical components at EnvMart for advanced industrial automation and electrical control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay supports a switching current of 10A.
This model operates on a 24V DC coil voltage.
It can manage AC switching voltages up to 250V.
The relay has compact dimensions of 29mm in length, 13mm in width, and 16.5mm in height.
It has a power rating of 4kVA.
This unit is designed for PCB mounting with a through-hole terminal type.
The coil power consumption is low at 250mW, contributing to its energy efficiency.
It operates within a temperature range of -40°C to 70°C.
The relay uses gold-plated contacts for reliable electrical connections.
It complies with TUV, UL, RoHS, IEC, VDE, and CE standards.
Typical applications include brake circuits, motor control systems, and time switches.
It features a Double Pole Double Throw (DPDT) contact configuration.
