HARWIN M80 Series Straight Through Hole 10-Contact, 2 Row, 2 mm Pitch PCB Socket M80-4101042

HARWIN M80-4101042 is a high reliability straight through hole PCB socket featuring 10 contacts arranged in 2 rows with a 2 mm pitch. It is engineered for board-to-board connection systems requiring robust electrical performance and mechanical strength. The housing is made from Polyphenylene Sulphide, providing excellent resistance to heat and chemicals, ideal for demanding industrial and electronic applications.

The internal contacts are crafted from Beryllium Copper Alloy with gold plating to ensure superior conductivity and minimal contact resistance. Rated for 12A current and 120V operating voltage, this socket performs reliably across a wide temperature range from -55°C to 125°C, making it suitable for harsh environments, including industrial and military applications.

This socket mounts via through-hole technology with a straight orientation, facilitating easy soldering and mechanical stability on printed circuit boards. Its female contact gender and board-to-board connector system type are designed to mate with compatible male plugs, ensuring secure and high integrity connections.

The M80 series, including this model, meets rigorous standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008, reflecting its suitability for commercial off-the-shelf (COTS) and industrial use cases. The series also offers various mounting options, including jackscrews and board mounts for enhanced retention.

This product is manufactured in the United Kingdom, assuring quality and traceability consistent with Harwin’s commitment to high-performance connectors. It is ideal for applications in electronics manufacturing, telecommunications, industrial controls, and other sectors where durability and reliability under vibration and shock are crucial.

Constructed with Polyphenylene Sulphide housing for durability. Features Beryllium Copper Alloy contacts with gold plating for excellent conductivity. Supports a current rating of 12A and voltage rating of 120V. Designed for through-hole mounting with straight orientation.

Operates reliably in temperatures from -55°C to 125°C. Connector type is female, suitable for board-to-board systems. Complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards. Manufactured in the United Kingdom ensuring high-quality standards.

Ideal for applications subject to high vibration, shock, and harsh environments. Compatible with industry-standard equivalents and available with optional Jackscrews or Board Mounts in the series. Explore HARWIN connectors and sockets categories on EnvMart for comprehensive industrial-grade electronic components tailored for high reliability and demanding applications.
