STMicroelectronics Operational Amplifier 22 MHz Gain Bandwidth Product, 5-Pin SOT-23 Package TSB7191IYLT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.45mm |
| Length | 3mm |
| Model | TSB7191IYLT |
| Width | 1.75mm |
| Mount Type | Surface |
| Low Noise | 12 nV/√Hz |
| Series | TSB7191 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | JEDEC, ANSI/ESD STM5.3.1 |
| Pin Count | 5 |
| Automotive Standard | AEC-Q3, AEC-Q100 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 2.7V |
| GBP - Gain Bandwidth Product | 22MHz |
| Input Bias Current | 0 nA |
| Slew Rate | 12V/μs |
| Input Offset Current | 10 nA |
| Extended temperature range | -40 °C to +125 °C |
Key Features
- Features rail-to-rail input and output operation for enhanced signal range.
- Operates from a single supply voltage range of 2.7 V to 36 V.
- Offers low input offset voltage of 300 μV maximum at 25 °C.
- Includes integrated EMI filter ensuring signal integrity.
- Extended operating temperature range from -40 °C to +125 °C.
- Low noise level of 12 nV/√Hz for precise amplification.
- Stable with gains from +10 to -9 for versatile circuit designs.
- Automotive graded and compliant with AEC-Q3 and AEC-Q100 standards.
Product Description
STMicroelectronics TSB7191IYLT is a high-performance operational amplifier featuring a gain bandwidth product of 22 MHz packed in a compact 5-Pin SOT-23 surface mount package. With rail-to-rail input and output capability, it supports a wide supply voltage range from 2.7 V to 36 V (single supply) and from ±1.35 V to ±18 V (dual supply), making it highly adaptable for diverse electronic applications.
This automotive-grade amplifier operates efficiently over an extended temperature range of -40 °C to +125 °C and meets automotive quality standards AEC-Q3 and AEC-Q100. Its precision low input offset voltage of 300 μV maximum at 25 °C ensures accurate signal processing with minimal error. The integrated EMI filter stabilizes the device against electromagnetic interference, while a slew rate of 12 V/μs and low noise density of 12 nV/√Hz provide fast and clean amplification.
The TSB7191IYLT is designed for versatile applications including motor control systems, power supply regulation, filters, actuator driving, hall effect sensor interfacing, and resistive transducer signal conditioning.
Rail-to-rail input and output operation enhances dynamic range. Low offset voltage supports precision measurements. Stable operation at gains from +10 to -9. Extended automotive temperature range ensures reliability in harsh environments.
Integrated EMI filter reduces interference and increases signal integrity. Compact SOT-23 package facilitates easy PCB integration. Compliance with JEDEC and ANSI/ESD STM5.3.1 standards guarantees quality and durability.
This Operational Amplifier is ideal for industrial, automotive, and consumer electronics applications requiring robust and precise amplification solutions. Explore more amplifiers and semiconductor components on EnvMart for all your electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 22 MHz.
It operates from a single supply voltage range of 2.7 V to 36 V and from ±1.35 V to ±18 V for dual supply configurations.
This operational amplifier has an extended operating temperature range from -40 °C to +125 °C.
The maximum input offset voltage is 300 μV at 25 °C.
The slew rate of this operational amplifier is 12 V/μs.
The dimensions of the SOT-23 package are 3 mm in length, 1.75 mm in width, and 1.45 mm in height.
It complies with AEC-Q3 and AEC-Q100 automotive standards.
The noise level is 12 nV/√Hz, which supports precise amplification.
This model has one channel.
It uses a surface mount type.
It includes an integrated EMI filter that ensures signal integrity by reducing electromagnetic interference.
This operational amplifier is suitable for applications such as motor control systems, power supply regulation, and sensor interfacing.
