Panasonic Polypropylene Film Capacitor 3.9 nF ±10% 300V AC Through Hole ECQUBAF392K
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 11.5mm |
| Length | 15.3mm |
| Model | ECQUBAF392K |
| Width | 5mm |
| Mount Type | Through Hole |
| Series | ECQUB |
| Maximum Operating Temperature | 110°C |
| Tolerance | ±10 % |
| Capacitance | 3.9nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Straight |
| Dissipation Factor | 0.1% |
| Lead Length | 20mm |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 300V ac |
| Lead Pitch | 12.5mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
Key Features
- This capacitor uses metallized polypropylene film for non-inductive construction.
- It supports through-hole mounting with straight terminals and 12.5 mm lead pitch.
- The operating temperature range is -40°C to 110°C, suitable for various applications.
- Flame-retardant plastic case and non-combustible resin enhance safety.
- It is compliant with AEC-Q200 automotive standard and international approvals like CSA, EN, and UL.
- Dissipation factor is low at 0.1%, ensuring efficient performance.
- Pin count is 2 with 0.6 mm lead diameter and 20 mm lead length.
- Designed for interference suppression in electronic equipment.
Product Description
Panasonic ECQUBAF392K is a high-quality polypropylene film capacitor featuring a capacitance of 3.9 nF with ±10% tolerance and a rated AC voltage of 300V. It is designed for through-hole mounting with straight terminals, having a lead pitch of 12.5 mm and leads measuring 20 mm in length. The capacitor has a compact size with dimensions approximately 15.3 mm length, 11.5 mm height, and 5 mm width, enclosed in a durable plastic case.
This model exhibits excellent electrical characteristics with a low dissipation factor of 0.1%, improving energy efficiency and reducing losses. The metallized polypropylene film construction ensures non-inductive behavior, suitable for high-frequency applications.
Operating temperature ranges from -40°C to 110°C, making it versatile for diverse industrial and automotive environments. It meets the AEC-Q200 automotive standard and international certification standards including CSA E60384-14, EN 60384-14, and UL 60384-14, reflecting its quality and reliability.
Panasonic ECQUBAF392K capacitor is primarily applied for interference suppression and is suitable for electronic equipment manufacturing, including industrial machinery, automotive electronics, and power supply circuits.
This capacitor features a flame-retardant plastic case and non-combustible resin for enhanced safety. It has a pin count of two and a lead diameter of 0.6 mm for secure electrical connections. The product complies with RoHS environmental standards, supporting eco-friendly applications.
Its compact form factor makes it suitable for space-constrained assemblies. High moisture resistance at 85°C and 85% relative humidity over 500 hours extends its durability in harsh conditions.
Overall, the Panasonic ECQUBAF392K is an ideal choice for engineers seeking reliable, efficient polypropylene film capacitors for demanding electronics and automotive applications.
Explore more Panasonic film capacitors and electronic components in the EnvMart catalog to meet diverse design requirements and industrial standards.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 3.9 nF with a tolerance of ±10%.
This capacitor has a rated AC voltage of 300V.
The dimensions are approximately 15.3 mm in length, 11.5 mm in height, and 5 mm in width.
It features a through-hole mounting type with straight terminals, a lead pitch of 12.5 mm, and a lead diameter of 0.6 mm.
The operating temperature range is from -40°C to 110°C.
The dissipation factor is low at 0.1%, which helps improve energy efficiency.
It complies with the AEC-Q200 automotive standard.
It is constructed with metallized polypropylene film and enclosed in a flame-retardant plastic case with non-combustible resin.
This capacitor has a pin count of 2 and a lead length of 20 mm.
It is primarily used for interference suppression in electronic equipment, including industrial machinery and automotive electronics.
It meets international certifications including CSA, EN, and UL standards, reflecting its compliance with safety and quality standards.
The country of origin for this capacitor is China.
