Crydom HD Series Solid State Relay Panel Mount 125A Load 530V AC Load 32V DC Control HD48125K
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 26.4mm |
| Length | 44.5mm |
| Model | HD48125K |
| Mount Type | Panel |
| Output type | SCR |
| Series | HD |
| Maximum Operating Temperature | 80°C |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 125A |
| Maximum Load Voltage | 530V ac |
| Minimum Load Voltage | 48V ac |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 1mArms |
Key Features
- This relay supports a maximum load current of 125 amperes.
- It is designed for panel mount application with screw terminal type for secure connections.
- The relay operates with a maximum load voltage of 530V AC and a minimum load voltage of 48V AC.
- Control voltage range spans from 4V DC minimum to 32V DC maximum, allowing flexible control options.
- Featuring zero cross switching function for safe and efficient operation.
- Certified to multiple standards including UL, CSA, CE, IEC, and VDE for reliable industrial use.
- Operating temperature range is from -40°C to 80°C suitable for diverse environments.
- Utilizes SCR output for heavy industrial loads providing high durability.
Product Description
Crydom HD48125K Solid State Relay is engineered for robust panel mount applications offering a maximum continuous load current of 125 amperes and handling up to 530V AC load voltage. It features a DC control input range from 4V to 32V, providing versatile control options for industrial automation systems.
Built with advanced Direct Bond Copper (DBC) substrate technology, this relay boasts superior thermal management ensuring reliable long-term operation. The epoxy-free design contributes to enhanced durability and resistance to environmental stresses.
This solid state relay includes zero cross switching functionality, which reduces electrical noise and prolongs load equipment life by switching at zero voltage crossing point. Its SCR output is suitable for heavy industrial loads commonly found in manufacturing, HVAC systems, and power management configurations.
The product meets stringent industry standards such as UL, CSA, CE, IEC, and VDE. It is compliant with EN 60950-1 and screened for immunity to electromagnetic interference, making it appropriate for critical electrical applications including control panels and industrial automation.
Designed to operate within a broad temperature range from -40°C to 80°C, the relay maintains performance in harsh conditions. Its sturdy screw terminal connections and anti-rotation barriers ensure secure mount and wiring integrity.
Maximum load current 125A for heavy industrial loads. Panel mount type with screw terminals for secure installation. Supports 530V AC maximum load voltage with 48V AC minimum. Control voltage from 4V DC to 32V DC allows flexible automation control.
Zero cross switching function enhances electrical performance and load longevity. Certified to UL, CSA, CE, IEC, VDE standards ensuring safety and compliance. Operates in extreme temperatures from -40°C to 80°C. Epoxy-free design with Direct Bond Copper substrate for superior thermal management.
Compact dimensions of 44.5mm length and 26.4mm height. Ideal for industrial, manufacturing, HVAC, and automation control applications.
Derating applies at ambient temperatures above 25°C. This Crydom solid state relay is a reliable choice for industrial electrical and automation circuits requiring silent operation and high endurance.
Explore more Solid State Relays and automation components available at EnvMart to meet diverse industrial control needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum load current of 125 amperes.
It operates within a temperature range from -40°C to 80°C, making it suitable for diverse environmental conditions.
The control voltage range spans from 4V DC minimum to 32V DC maximum, allowing for flexible control options in automation systems.
It features a zero cross switching function, which helps reduce electrical noise and prolongs the life of connected load equipment.
The relay has a length of 44.5mm and a height of 26.4mm.
This model can handle a maximum load voltage of 530V AC and a minimum load voltage of 48V AC.
It utilizes screw terminal connections for secure installation and wiring integrity.
Yes, it is designed for heavy industrial loads and is suitable for applications in manufacturing, HVAC systems, and power management.
It is certified to multiple standards, including UL, CSA, CE, IEC, and VDE, ensuring compliance and safety for industrial use.
The output type is SCR, which is suitable for handling heavy industrial loads.
The off state leakage current is rated at 1mArms.
The epoxy-free design enhances durability and resistance to environmental stresses, contributing to reliable long-term operation.
