Crydom CW Series Solid State Relay Panel Mount 10A Load 280V AC Load 32V DC Control CWD2410P
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | Crydom |
| Height | 22.6mm |
| Length | 44.5mm |
| Model | CWD2410P |
| Mount Type | Panel |
| Output type | SCR |
| Series | CW |
| Maximum Operating Temperature | 80°C |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 10A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 280V ac |
| Minimum Load Voltage | 24V ac |
| Minimum Control Voltage | 3V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 1mArms |
Key Features
- Supports a maximum load current of 10 amperes.
- Designed for panel mounting with screw terminal type connections.
- Operates at a maximum load voltage of 280V AC and minimum load voltage of 24V AC.
- Control voltage ranges from 3V DC minimum to 32V DC maximum.
- Features zero cross switching for improved resistive load performance.
- Compact dimensions measuring 44.5mm in length and 22.6mm in height.
- Operating temperature range from -40°C to 80°C enables use in diverse environments.
- Solid state output type using back-to-back SCR for industrial reliability.
Product Description
Crydom CWD2410P Solid State Relay is a panel mount device designed for commercial and heavy industrial applications requiring reliable AC load switching up to 10 amperes at 280V AC. It features a back-to-back SCR output type providing efficient zero crossover switching, optimized for resistive loads. The device includes a removable IP20 touchsafe cover to enhance operator safety and an epoxy-free design for environmental resilience.
The relay accepts control voltages from 3V DC up to 32V DC, allowing flexible interfacing with various control systems. It mounts securely via screw terminals, with anti-rotation barriers in the housing to guarantee stable installation within control panels.
Compact and robust, the relay measures 44.5mm in length and 22.6mm in height, operating reliably across a wide temperature range from -40°C to 80°C, making it suitable for diverse industrial environments, including manufacturing, automation, HVAC, and process control systems.
Additional features include compliance with the Restriction of Hazardous Substances (RoHS), a capacitance rating of 8pF, and a low 1mArms off-state leakage current, supporting energy-efficient and safe operation. The solid state construction delivers improved thermal performance through a DBC substrate.
Supports a maximum load current of 10 amperes. Designed for panel mounting with screw terminal type connections. Operates at a maximum load voltage of 280V AC and minimum load voltage of 24V AC. Control voltage ranges from 3V DC minimum to 32V DC maximum.
Features zero cross switching ideal for resistive loads. Compact size for easy installation in control panels. Wide operating temperature range from -40°C to 80°C for versatility. Epoxy-free design with RoHS compliance for environmental safety.
Includes removable IP20 touchsafe cover enhancing user safety. Low off-state leakage current and SCR output for reliable industrial control.
This Crydom CW Series Solid State Relay is manufactured in Mexico and represents a reliable component choice for electrical, industrial automation, manufacturing, and HVAC sectors. It is designed to provide long service life and minimal maintenance within panel-mounted control systems.
Explore EnvMart’s comprehensive range of industrial electrical relays and automation components to find compatible and complementary products designed for heavy-duty and precision applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this solid state relay is 10 amperes.
It operates at a maximum load voltage of 280V AC and a minimum load voltage of 24V AC.
This model accepts control voltages ranging from 3V DC to 32V DC.
It features zero cross switching, which is ideal for improving performance with resistive loads.
The relay measures 44.5mm in length and 22.6mm in height.
The operating temperature range is from -40°C to 80°C, allowing for use in diverse environments.
It uses screw terminal type connections for secure mounting.
Yes, it complies with the Restriction of Hazardous Substances (RoHS) standard.
The off-state leakage current is rated at 1mArms.
This relay is manufactured in Mexico.
The output type is SCR (Silicon Controlled Rectifier), which provides reliable performance for industrial applications.
It is suitable for commercial and heavy industrial applications, including manufacturing, automation, HVAC, and process control systems.
