i-Autoc KSI Series Solid State Relay Panel Mount 60 A Load 280 V Ac Load 32 V Control KSI240D60-L(068)

The i-Autoc KSI240D60-L(068) Solid State Relay is a robust and reliable panel mount industrial relay designed for single-phase loads up to 60 amperes at 280 V AC. It features zero cross switching technology, which reduces electrical noise and enhances relay lifespan when switching resistive, inductive, and capacitive loads.

This relay accepts a wide control voltage range from 4 V up to 32 V DC and is terminated with screw terminals for secure connections. It is IP20 rated, safeguarding users from accidental contact, and operates reliably within a temperature range of -30°C to 80°C.

With a compact size of 27 mm height, 58.6 mm length, and 45.7 mm width, this solid state relay integrates easily into panel installations without requiring excessive space. Its off-state leakage current is minimal at 5 mA, improving energy efficiency and reducing unintended current flow when switched off.

Internally, the device incorporates RS/MOV and TVS protections to handle voltage surges, ensuring durability in harsh industrial environments. It is suitable for a variety of industrial sectors including HVAC, plastics machinery, elevator control systems, lighting controls, and high-low temperature chambers.

The relay complies with important certifications such as CCC, CE, and RoHS, providing users assurance of quality, safety, and environmental responsibility. The relay enables zero cross switching for reduced electrical transients.

It supports loads up to 60 A and voltages up to 280 V AC. Control voltage ranges from 4 V to 32 V DC. It features SCR and triac output types. Compact panel mount design with IP20 touch-safe cover. Suitable for resistive, inductive, and capacitive loads.

Wide operating temperature from -30°C to 80°C. Internal surge protection with RS/MOV and TVS components. Applications include industrial automation, HVAC, plastics machinery, and elevators. Certified with CCC, CE, and RoHS approvals.

This product belongs to the Solid State Relay category on EnvMart, optimized for industrial and commercial automation control systems. Explore more Solid State Relays and related products to suit your application requirements.
