Microchip 4-Channel 12-bit Successive Approximation Register Analogue to Digital Converter 100 ksps 14-Pin MCP3204-CI/ST
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 12 bit |
| Brand | Microchip |
| Height | 1.2mm |
| Length | 5.1mm |
| Model | MCP3204-CI/ST |
| Mount Type | Surface |
| Sampling rate | 100ksps |
| Series | MCP3204 |
| Input Type | Voltage |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Interface Type | SPI |
| Architecture | SAR |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
| Number of ADCs | 4 |
Key Features
- The ADC provides high resolution of 12 bits for accurate analog signal conversion.
- Supports SPI interface for communication and control.
- Operates over a supply voltage range of 2.7V to 5.5V.
- Designed for operation between -40°C and 85°C, making it suitable for automotive environments with AEC-Q100 certification.
- Compact surface mount TSSOP package with 14 pins measuring 5.1mm in length and 1.2mm in height.
- Features 4 separate ADC channels for simultaneous data acquisition.
- Ideal for applications requiring precise voltage input sampling and conversion.
- Suitable for embedded systems, industrial instrumentation, automotive electronics, and data acquisition systems.
Product Description
Microchip MCP3204-CI/ST is a 4-channel, 12-bit resolution analogue to digital converter (ADC) designed using successive approximation register (SAR) architecture, delivering a sampling rate of 100 ksps. It is packaged in a compact 14-pin TSSOP surface mount package, ideal for modern electronic designs requiring space efficiency.
The device supports SPI communication, allowing seamless integration with microcontrollers and other digital devices for precise analog voltage measurement. Operating over a supply voltage range from 2.7V up to 5.5V, it provides flexibility for various power supply designs.
Engineered for reliability, the MCP3204-CI/ST is qualified under the AEC-Q100 automotive standard and can operate in temperature ranges from -40°C to +85°C, making it suitable for automotive and industrial environments where temperature extremes and robustness are critical.
This ADC features 4 independent input channels, allowing simultaneous analog-to-digital conversion from multiple sensors or signals. Its 12-bit resolution enables high-precision measurements, useful in instrumentation, data acquisition, and embedded control applications.
The device’s compact size (5.1mm length and 1.2mm height) allows it to fit into dense circuit layouts. Its SAR architecture ensures low power consumption and fast conversion times. Applications include automotive sensor interfacing, industrial control systems, medical instrumentation, and consumer electronics.
Key features include voltage input compatibility, surface mount assembly, and high operating temperature tolerance. Microchip offers comprehensive technical documentation and design resources to support integration.
For professionals in electronic design and manufacturing, the MCP3204-CI/ST ADC provides a reliable, compact, and precise solution for analog signal processing needs. Explore more Microchip semiconductor components and analogue converters for your technical projects on EnvMart.
Explore more products in our Analogue to Digital Converters category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a resolution of 12 bits, allowing for accurate analog signal conversion.
The MCP3204-CI/ST has a maximum sampling rate of 100 ksps, enabling rapid data acquisition from multiple channels.
It operates over a supply voltage range of 2.7V to 5.5V, providing flexibility for various power supply designs.
This ADC supports 4 independent input channels for simultaneous analog-to-digital conversion.
The MCP3204-CI/ST supports SPI communication, facilitating integration with microcontrollers and other digital devices.
It is packaged in a compact 14-pin TSSOP format, measuring 5.1mm in length and 1.2mm in height.
The MCP3204-CI/ST is designed for operation in temperatures ranging from -40°C to +85°C, suitable for automotive applications.
Yes, it is qualified under the AEC-Q100 automotive standard, ensuring reliability in automotive environments.
The MCP3204-CI/ST accepts voltage as its input type, making it suitable for various analog voltage measurements.
It utilizes a successive approximation register (SAR) architecture, which ensures efficient analog-to-digital conversion.
The MCP3204-CI/ST has a pin count of 14, allowing for compact integration into electronic designs.
This ADC is suitable for applications in embedded systems, industrial instrumentation, automotive electronics, and data acquisition systems.
