Texas Instruments 8 Channel 12 Bit SAR ADC 200 ksps Sampling Rate 16-Pin TSSOP ADC128S022CIMT/NOPB

Texas Instruments ADC128S022CIMT/NOPB is an 8 channel analogue to digital converter (ADC) featuring 12 bit resolution and a sampling rate of 200 ksps. This ADC uses a successive approximation register (SAR) architecture to deliver efficient and quick signal conversions, ideal for various electronic applications.

Packaged in a 16-Pin TSSOP surface mount format with dimensions of 5.4mm in length and 1.2mm in height, it ensures compact integration into designs requiring small form factors. The device operates on a minimum supply voltage of 3.3V and accepts voltage-type inputs.

The ADC supports multiple interface types including SPI, QSPI, and Microwire, providing enhanced flexibility for communication with digital systems. It functions reliably over a wide temperature range, from -40°C to 105°C, making it suited to industrial, laboratory, and embedded electronics applications.

This product has not been certified for automotive use and does not carry additional standards or approvals, aligning it primarily with general electronic component usage. The ADC features an 8 channel input and 12 bit resolution for precise signal digitization.

Built on successive approximation register (SAR) architecture ensuring efficient conversions. Operates at a minimum supply voltage of 3.3V with voltage input type. Compatible with SPI, QSPI, and Microwire interface types for flexible connectivity.

Designed for surface mount with a compact 5.4mm length and 1.2mm height package. Suitable for operating temperatures from -40°C to 105°C. Package type is TSSOP with 16 pins for reliable electrical connections. This product does not comply with automotive standards and has no special certifications.

Typical industrial, laboratory, and electronic equipment sectors will find this ADC suitable for conversion tasks requiring multiple inputs and high-speed operation. Its robust temperature range and compact package size enable implementation in a variety of embedded systems and control devices.
