BOURNS 1038 Shielded Wirewound Surface Mount Inductor Carbonyl Powder Core 47μH ±20% 3 A Idc Q:20 SRP1038A

Free Delivery in India | Lowest Global Shipping Charges

BOURNS 1038 Shielded Wirewound Surface Mount Inductor Carbonyl Powder Core 47μH ±20% 3 A Idc Q:20 SRP1038A

Name: BOURNS 1038 Shielded Wirewound Surface Mount Inductor Carbonyl Powder Core 47μH ±20% 3 A Idc Q:20 SRP1038A
Brand: BOURNS
SKU: 377205
Price: 1 USD
Availability: InStock



Category Surface Mount Inductors Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	3.8mm
Length	11mm
Model	SRP1038A
Depth	10mm
Packaging	Reel
Series	SRP1038A
Maximum Operating Temperature	150°C
Minimum Operating Temperature	-40°C
Core Material	Carbonyl Powder
Inductance	47μH
Standards/Approvals	RoHS
Package/Case	1038
Maximum DC Current	3A
Pin Count	2
Maximum DC Resistance	167mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	5MHz
Minimum Quality Factor	20
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200

Key Features

Features a magnetically shielded construction ensuring minimal electromagnetic interference.
Constructed with a carbonyl powder core providing high saturation current.
Designed for surface mount applications with a compact 1038 package size.
Supports automotive standards with AEC-Q200 certification for reliability.
Maximum operating temperature of 150°C suits demanding environments.
Low maximum DC resistance of 167mΩ ensures efficient performance.
Inductance tolerance is ±20% with a minimum quality factor of 20 for stable operation.
Termination style is solder with a pin count of 2 for ease of PCB mounting.

Product Description

BOURNS SRP1038A is a high-quality shielded wirewound surface mount inductor featuring a carbonyl powder core and designed for effective magnetic interference reduction and high saturation currents. This inductor offers an inductance of 47μH with a tolerance of ±20%, suitable for applications requiring precise inductance in a compact surface mount form factor.

The device complies with the automotive industry standard AEC-Q200, making it ideal for automotive systems such as driver assistance, information, entertainment, and lighting systems. With a maximum DC current rating of 3 A and low DC resistance at 167mΩ, it delivers efficient performance in demanding electronics.

Its packaging in a 1038 reel and height of 3.8mm with a depth of 10mm allows for easy integration on PCBs with a termination style optimized for soldering. Operating temperature ranges from -40°C to 150°C, with a minimum quality factor of 20 and a maximum self-resonant frequency of 5MHz, enhancing reliability in power supplies and DC/DC converters.

The inductor’s wirewound construction combined with a moulded design ensures durability and stability against mechanical and thermal stresses. The magnetic shielded design reduces electromagnetic interference contribution in sensitive electronic environments.

Key applications include automotive electronics and general power management in industrial and commercial electronic assemblies. The product is RoHS compliant, promoting environmental safety in manufacturing and disposal.

Features magnetically shielded construction for interference reduction. Carbonyl powder core enhances saturation current handling. Complies with automotive standard AEC-Q200 for reliability. Compact 1038 surface mount package facilitates PCB integration.

Solder termination and 2-pin design ensures secure mounting. Wide operating temperature range from -40°C to 150°C. Supports DC/DC converters and automotive system uses. RoHS compliant for environmental safety. High-quality factor (Q=20) enables efficient power management.

Maximum self-resonant frequency of 5MHz for high-frequency applications. Explore more Surface Mount Inductors from Bourns and discover a wide range of components tailored for electronic and electrical applications at EnvMart.
