Panasonic Shielded Power Choke Coil with Metal Composite Core 1.9 μH ±20% 29.8 A Idc Surface Mount ETQP5M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 10.9mm |
| Model | ETQP5M |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | ETQP5M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 1.9μH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 29.8A |
| Pin Count | 2 |
| Maximum DC Resistance | 4.9mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed for high heat resistance up to 150°C including self-heating.
- Robust design with high vibration resistance suitable for automotive use.
- Features low audible buzz noise ensuring quiet operation.
- Provides excellent inductance stability over a wide temperature range.
- Utilizes ferrous alloy magnetic material for high bias current capacity.
- Includes shielded construction to minimize interference.
- Surface mount termination style for easy PCB integration.
- Complies with RoHS standards and automotive AEC-Q200 qualification.
Product Description
Panasonic ETQP5M shielded power choke coil with metal composite core is a high-performance surface mount inductor specially designed for automotive and industrial applications. This power choke coil provides an inductance of 1.9 μH with a tolerance of ±20% and withstands a maximum DC current of 29.8 A, making it suitable for high current circuits.
The inductor is constructed with a metal composite core that enhances robustness and reliability. Its design delivers excellent inductance stability across a wide temperature range from -40°C to 150°C, supporting high heat resistance including self-heating conditions.
Featuring a shielded construction, the ETQP5M reduces electromagnetic interference, ensuring quieter operation with low audible buzz noise. Its wirewound and moulded construction underlines durability and vibration resistance, meeting the stringent requirements of the AEC-Q200 automotive standard.
The component is surface mount type with a pin count of 2, dimensions measuring 10.9 mm in length, 5 mm in height, and 5 mm in depth. It has a maximum DC resistance of 4.9 mΩ and a maximum self-resonant frequency of 100 kHz, ensuring efficient operation with minimal losses.
This inductor is ideal for use in automotive electronics, industrial equipment, power supply circuits, and other demanding applications requiring high reliability and stable inductance performance.
High heat resistance operating up to 150°C including self-heating. Robust and vibration-resistant integral construction for automotive use. Low DC resistance and eddy current losses for high efficiency. Shielded construction minimizes electromagnetic interference.
Compliant with RoHS and automotive AEC-Q200 standards. Compact surface mount design suitable for space-constrained applications. Stable inductance with ferrous alloy magnetic core material. Wirewound coil construction with moulded body.
Maximum DC current rating of 29.8 A for high power circuits. Maximum self-resonant frequency of 100 kHz.
This Panasonic power choke coil is available in tape and reel packaging, facilitating automated PCB assembly processes. Explore more components in the Surface Mount Inductors category at EnvMart for your industrial and commercial electronics needs.
Explore more products in our Power Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 1.9 μH with a tolerance of ±20%.
This power choke coil has a maximum DC current rating of 29.8 A, suitable for high power circuits.
It can operate within a temperature range of -40°C to 150°C, including conditions of self-heating.
The ETQP5M features a wirewound coil construction with a moulded body, enhancing its robustness and reliability.
The shielded construction minimizes electromagnetic interference, ensuring quieter operation with low audible buzz noise.
This model measures 10.9 mm in length, 5 mm in height, and 5 mm in depth.
The maximum self-resonant frequency for this power choke coil is 100 kHz.
It uses a surface mount termination style, facilitating easy integration into PCBs.
Yes, it complies with RoHS standards and the automotive AEC-Q200 qualification.
The maximum DC resistance for this inductor is 4.9 mΩ, ensuring efficient operation.
It is available in tape and reel packaging, which is suitable for automated PCB assembly processes.
This power choke coil is designed for automotive electronics, industrial equipment, and power supply circuits requiring high reliability.
