Panasonic Shielded Wirewound Surface Mount Inductor 1.5 μH ±20% 9.1 A Idc Metal Composite Core ETQP3M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 3mm |
| Length | 6.4mm |
| Model | ETQP3M |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | ETQP3M |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 1.5μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 9.1A |
| Pin Count | 2 |
| Maximum DC Resistance | 12.1mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a shielded wirewound design for improved inductance stability.
- Constructed with a metal composite core for high heat resistance and reliability.
- Supports operation up to 155°C for high-temperature circuit applications.
- Designed to handle high bias current and low audible noise performance.
- Comes in a compact surface mount package measuring 6.4 mm length and 3 mm height.
- Packaged with tape and reel for efficient automated assembly.
- Conforms to RoHS standards and automotive AEC-Q200 certification.
- Offers ±20% inductance tolerance suitable for various drive circuitry noise filtering.
Product Description
Panasonic ETQP3M1R5KVN Shielded Wirewound Surface Mount Inductor features a metal composite core that ensures high heat resistance and robustness. This wirewound inductor is engineered for industrial, automotive, and electronic applications requiring stable inductance under high current and temperature stresses.
Its shielded construction minimizes electromagnetic interference, delivering consistent performance up to 155°C operating temperature. The compact 6.4 mm by 3 mm surface mount package facilitates space-saving PCB layouts. Ideal for noise filtering and power management in automotive electronics and high-reliability industrial systems.
The integral construction provides exceptional vibration resistance, making it suitable for harsh environments. The 9.1 A maximum DC current rating supports high bias current operations while maintaining low audible noise levels, enhancing device longevity and signal integrity.
Compliance with RoHS and AEC-Q200 automotive safety standards further ensures quality and application reliability. The device is supplied in tape and reel packaging, enabling seamless automated pick-and-place assembly processes.
Shielded wirewound design for superior inductance stability. Metal composite core with high heat and vibration resistance. Operates reliably at up to 155°C for demanding environments. Compact surface mount form factor with 2 pins.
Designed to handle up to 9.1 A DC current safely. Low DC resistance of 12.1 mΩ reduces power losses. ±20% inductance tolerance supports varied electronic requirements. RoHS compliant and AEC-Q200 standard for automotive use.
Packaged on tape and reel for efficient manufacturing.
This inductor is ideally suited for industrial electronics, automotive power circuits, and other applications requiring stable inductors with high current handling and temperature endurance. Explore more Surface Mount Inductors on EnvMart for comprehensive solutions.
Explore more products in our Power Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 1.5 μH with a tolerance of ±20%.
It has a maximum DC current rating of 9.1 A, making it suitable for high bias current applications.
The surface mount package measures 6.4 mm in length, 6 mm in depth, and 3 mm in height.
This model operates reliably within a temperature range of -55°C to 155°C.
It features a metal composite core, which provides high heat resistance and robustness.
It is packaged on tape and reel, facilitating efficient automated assembly processes.
It conforms to RoHS standards and is certified under the AEC-Q200 automotive standard.
This inductor is constructed using a wirewound design, which enhances inductance stability.
The maximum DC resistance is 12.1 mΩ, which helps reduce power losses during operation.
It is designed for use in industrial electronics, automotive power circuits, and applications requiring stable inductance under high current and temperature conditions.
This model has a pin count of 2, suitable for surface mount applications.
The shielded design minimizes electromagnetic interference, ensuring consistent performance in various applications.
