Bourns Shielded Wirewound Surface Mount Inductor 15 μH ±20% 5 A IDC 17.6 MHz Q:25 Ferrite Core SRR1260
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 6mm |
| Length | 12.5mm |
| Model | SRR1260 |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | SRR1260 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 15μH |
| Standards/Approvals | RoHS |
| Package/Case | 1260 |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 727-2237PBrand: BournsManufacturers Part No.: SRR1260-150M |
| Maximum DC Current | 5A |
| Maximum DC Resistance | 27mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 17.6MHz |
| Minimum Quality Factor | 25 |
| Inductor Construction | Wirewound |
Key Features
- The inductor features a ferrite core with magnetic shielding for reduced interference.
- Designed for surface mount with a compact 1260 package size and 6 mm height.
- Operates reliably between -40°C and 125°C temperature range.
- Maximum DC resistance is 27 mΩ ensuring efficient current flow.
- Max self-resonant frequency is 17.6 MHz with a minimum quality factor of 25.
- Molded construction with wirewound inductor technology ensuring durability.
- Ideal for DC/DC converter input/output in portable communication devices and consumer electronics.
- RoHS compliant, assuring environmental and safety standards.
Product Description
Bourns SRR1260 Shielded Wirewound Surface Mount Inductor is designed with a ferrite core and offers 15 μH inductance with a tolerance of ±20%. It supports a maximum DC current of 5 A and operates effectively up to 125°C, making it suitable for high-frequency and high-current power supply environments.
This low-profile inductor features a compact 1260 package with dimensions of 12.5 mm length, 6 mm height, and 12.5 mm depth, optimized for surface mount technology. Its magnetic shielding reduces electromagnetic interference, enhancing circuit stability. The device exhibits a maximum DC resistance of 27 mΩ, ensuring minimal power loss during operation.
With a high self-resonant frequency of 17.6 MHz and a quality factor of at least 25, it is ideal for applications in portable communication equipment, camcorders, LCD TVs, and car radios where efficient energy storage and transfer are critical.
The SRR1260 series is wirewound and molded for mechanical strength and thermal stability. Its RoHS compliance guarantees it meets environmental safety regulations for electronic components.
The inductor’s ferrite core and shielding provide high performance in noisy electrical environments. Compact surface mount package supports high-density PCB layouts. Wide operating temperature range enables use in diverse industrial conditions.
Low DC resistance ensures energy efficiency in power circuits. High resonance frequency and quality factor suit advanced power supply modules. Robust wirewound construction enhances reliability and endurance. Suitable for industrial, consumer electronics, and communication system applications.
Explore the range of Bourns inductors on EnvMart for premier quality electronic components tailored for demanding power and signal integrity requirements.
Explore more products in our Power Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SRR1260 inductor has an inductance value of 15 μH with a tolerance of ±20%.
This inductor supports a maximum DC current of 5 A.
The maximum operating temperature for the SRR1260 inductor is 125°C.
The minimum operating temperature for this model is -40°C.
The dimensions of this inductor are 12.5 mm in length, 6 mm in height, and 12.5 mm in depth.
The maximum self-resonant frequency of the SRR1260 is 17.6 MHz.
This model has a minimum quality factor of 25.
The SRR1260 inductor features a ferrite core material.
The termination style of this inductor is surface mount.
Yes, the SRR1260 is RoHS compliant, ensuring it meets environmental safety regulations.
The SRR1260 is constructed using wirewound technology, which enhances its mechanical strength and thermal stability.
This inductor is packaged in a reel format.
