onsemi MC74VHC04DR2G Inverter 6 Elements CMOS Logic IC, 14-Pin SOIC Package MC74VHC04DR2G

onsemi MC74VHC04DR2G is a 6-element inverter logic IC in a 14-pin SOIC surface-mount package that operates over a supply voltage range of 2.0 to 5.5 volts. This device belongs to the high-speed 74VHC (Very High-speed CMOS) family, combining advanced CMOS technology for low power dissipation and high performance suitable for a variety of industrial and electronic applications.

This inverter IC features a maximum propagation delay of 12 nanoseconds at typical load capacitance, ensuring rapid and reliable switching. It is designed without Schmitt trigger inputs and outputs Bipolar Schottky TTL compatible signals, which are well suited for interface with TTL logic systems.

The temperature operating range from -40°C to +85°C makes the MC74VHC04DR2G ideal for use in harsh industrial environments, including automotive and manufacturing control systems. Its compact dimensions of 8.75 mm (length) by 4 mm (width) by 1.5 mm (height) allow for high-density mounting on printed circuit boards (PCBs).

The package type is Small Outline Integrated Circuit (SOIC), compatible with automated surface mounting processes, facilitating efficient assembly in automated electronics manufacturing. The 14 pins provide connectivity for all six inverter elements and power supplies in a streamlined footprint.

Typical applications for the MC74VHC04DR2G include signal inversion in digital logic circuits, buffer and driver stages, and general-purpose inverting functions in embedded systems, industrial control, instrumentation, and communication devices.

Operates at a voltage range from 2.0 to 5.5 V allowing flexible power supply options. Contains 6 inverter elements per chip enabling multiple inverting stages within one IC. Surface mount SOIC package with 14 pins for compact and efficient PCB layout.

Bipolar Schottky TTL output type suitable for interfacing with TTL logic families. Wide operating temperature range of -40°C to 85°C suitable for industrial applications. Compact physical dimensions of 8.75 mm length, 4 mm width, and 1.5 mm height.

Low power CMOS technology ensures energy efficient operation. Maximum propagation delay time of 12 ns supports high-speed digital switching. Reliable inverter chip for industrial, automotive, laboratory, and manufacturing electronics.

This product is ideal for electronics engineers and designers requiring dependable inverter logic ICs for various control and signal processing applications in industrial automation, semiconductor manufacturing, and instrumentation technologies.

Explore the wide selection of semiconductor and Logic ICs available at EnvMart to support your design and production needs.
