onsemi Inverter IC 6 Elements, 14-Pin SOIC, CMOS LSTTL Output, 2 to 6 V Operating Voltage MC74HC04ADR2G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Inverter IC 6 Elements, 14-Pin SOIC, CMOS LSTTL Output, 2 to 6 V Operating Voltage MC74HC04ADR2G

Name: onsemi Inverter IC 6 Elements, 14-Pin SOIC, CMOS LSTTL Output, 2 to 6 V Operating Voltage MC74HC04ADR2G
Brand: onsemi
SKU: 374317
Price: 0.23 USD
Availability: InStock



Category Logic ICs Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	8.75mm
Model	MC74HC04ADR2G
Width	4mm
Mount Type	Surface
Compatibility	Input CMOS, Output CMOS
Output type	CMOS, LSTTL
Series	MC74HC04A
Input Type	Single Ended
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-55°C
Operating Voltage	2 to 6 V
Pin Count	14
Number of Elements per Chip	6
Automotive Standard	AEC-Q100
Maximum Supply Voltage	6V
Logic Family	74HC
Logic Function	Inverter
Minimum Supply Voltage	2V
Maximum High Level Output Current	-5.2mA
Maximum Propagation Delay Time @ CL	110ns
Maximum Low Level Output Current	5.2mA

Key Features

Operates at a voltage range of 2 to 6 V for versatile application use.
Includes 6 inverter elements integrated on a single chip.
Output supports CMOS and LSTTL logic families for compatibility.
Surface mount type with a compact SOIC package footprint.
Wide operating temperature from -55°C to 125°C for industrial environments.
Maximum propagation delay time of 110 ns ensures swift signal processing.
Complies with automotive standard AEC-Q100 for reliable automotive use.

Product Description

onsemi MC74HC04ADR2G is a high-speed CMOS Logic Inverter IC designed to provide 6 inverter elements integrated into a 14-pin small outline integrated circuit (SOIC) package. This component offers CMOS and LSTTL compatible outputs and operates efficiently within a supply voltage range of 2 to 6 volts. Its surface mount configuration makes it suitable for modern PCB designs requiring compact and reliable logic functions.

This inverter IC delivers rapid propagation delay times up to 110 ns at capacitive loads, making it ideal for applications requiring fast switching speeds. It supports single-ended input signals and does not include Schmitt Trigger inputs, optimizing it for usual inverter logic operations.

The device is engineered to perform over a broad temperature range from -55°C to 125°C, complying with the AEC-Q100 automotive qualification, ensuring robust function in automotive and industrial environments. Its compact footprint of 8.75 mm length by 4 mm width and 1.5 mm height makes it suitable for space-constrained assemblies.

Typical industrial use cases include logic inversion in electronic circuits for automotive electronics, industrial controllers, consumer electronics, and general-purpose signal conditioning where precise, high-speed logic inversion is required.

Operates within 2 - 6 V supply voltage ensuring compatibility with various voltage levels. Integrates 6 inverter gates per chip for multiple logic functions. Surface mount SOIC-14 package facilitates PCB assembly in modern electronic devices.

Designed for high-speed logic with a maximum propagation delay of 110 ns. Wide operating temperature makes it suitable for automotive and industrial use. Complies with automotive standards AEC-Q100 assuring reliability in harsh conditions.

Compact size optimizes space in electronic assemblies. Explore a wide range of semiconductor Logic ICs at EnvMart suitable for diverse industrial and commercial applications.
