STMicroelectronics Operational Amplifier, 1.3 MHz Gain Bandwidth Product, 5-Pin SOT-23 Package LMV321RIYLT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3mm |
| Model | LMV321RIYLT |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | LMV321 |
| Output Current | 46mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 2.7V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 95 nA |
| Vos - Input Offset Voltage | 6 mV |
| Slew Rate | 0.45V/μs |
| Input Offset Current | 25 nA |
| Low supply current | 145 μA |
| Gain bandwidth product | 1 MHz |
| Electrostatic Discharge (ESD) tolerance | 2 kV |
Key Features
- Single channel operational amplifier suitable for battery-powered and portable equipment.
- Wide operating supply voltage range from 2.7V to 6V.
- Low supply current consumption of 145 μA for power efficiency.
- Rail-to-rail input and output for maximum signal swing in low voltage applications.
- Slew rate of 0.45 V/μs supporting moderate signal speeds.
- Designed to operate over a temperature range of -40°C to 125°C.
- Compact dimensions with a height of 1.3 mm, length of 3 mm, and width of 1.75 mm.
- Electrostatic discharge tolerance up to 2 kV ensuring robustness in industrial environments.
Product Description
STMicroelectronics LMV321RIYLT is a single-channel operational amplifier with a gain bandwidth product of 1.3 MHz, housed in a compact 5-pin SOT-23 surface mount package. It is optimized for low-power applications including battery-operated and portable electronics.
This operational amplifier operates efficiently with a supply voltage range of 2.7 V to 6 V and features rail-to-rail input and output capabilities, maximizing the signal range in low voltage environments. Its low supply current of 145 μA contributes to extended battery life in portable applications.
The LMV321RIYLT supports a slew rate of 0.45 V/μs, suitable for typical analog signal processing tasks. It is rated to operate over an industrial temperature range from -40°C to 125°C, making it reliable in harsh conditions. Electrostatic discharge tolerance up to 2 kV ensures device robustness during handling and operation.
Its compact physical dimensions (height 1.3 mm, length 3 mm, width 1.75 mm) facilitate high-density PCB layouts. The device complies with RoHS environmental standards and meets the AEC-Q100 automotive standard, ensuring quality and safety in automotive electronics.
Typical applications encompass industrial automation, automotive sensor conditioning, portable instrumentation, and general purpose signal amplification in electronics design and manufacturing.
Single channel low power operational amplifier. Wide input and output voltage range with rail-to-rail operation. Low supply current for efficient power use in battery-powered devices. Extended operating temperature suitable for industrial environments.
Compact SOT-23 package for space-saving designs. Robust ESD protection up to 2 kV. Compliant with RoHS and automotive-grade AEC-Q100 certification. Designed for reliable performance in harsh industrial and automotive settings.
Ideal for portable, industrial, automotive, and general electronics applications. Enhances production efficiency with surface mount packaging. Explore the full range of STMicroelectronics Operational Amplifiers and related components in our Electronics & Electricals category for precision signal amplification solutions.
