STMicroelectronics Operational Amplifier, 8 kHz Gain Bandwidth, 14-Pin TSSOP, 1.5V to 5.5V Supply, Surface Mount TSU104IPT

STMicroelectronics TSU104IPT is a high-performance operational amplifier designed for compact and efficient electronics applications. This 4-channel amplifier features a 14-pin TSSOP surface mount package that facilitates easy integration into modern PCB layouts. Its gain bandwidth product of 8 kHz allows for effective signal amplification with minimal distortion, supporting both industrial and laboratory use cases.

The device supports a supply voltage range from 1.5V to 5.5V, making it versatile for low power systems. Its low input bias current of 30 pA and input offset voltage of 3.4 mV contribute to high signal fidelity and accurate measurement, critical for instrumentation and control applications.

Operating reliably in temperatures ranging from -40°C to 85°C, this operational amplifier suits harsh environments, including automotive and industrial electronics. The 3 V/ms slew rate ensures quick response to changing input signals, improving performance in dynamic systems.

With a max output current of 4 mA, the TSU104IPT can drive downstream components effectively. Its compact physical dimensions of 5.1 mm by 4.5 mm by 1.05 mm optimize PCB space usage. The inclusion of RoHS compliance ensures adherence to environmental regulations.

This operational amplifier finds applications in industrial control systems, instrumentation, consumer electronics, and embedded systems requiring precision and reliability. TSU104IPT is ideal for users seeking efficient amplification in a small footprint with wide operating conditions.

Designed for surface mounting, enabling compact PCB assemblies. Features a typical gain bandwidth product of 8 kHz for precise amplification. Operates at a low input bias current of 30 pA, minimizing signal distortion. Wide operating temperature range from -40°C to 85°C for diverse environments.

Includes low input offset voltage of 3.4 mV ensuring accurate signal processing. Compact dimensions of 5.1 mm length, 4.5 mm width, and 1.05 mm height. Supports maximum output current of 4 mA suitable for signal drive applications.

RoHS compliant ensuring environmental and safety standards. Optimized slew rate of 3 V/ms for responsive signal changes. Suitable for industrial, laboratory, and electronics manufacturing applications. Explore the STMicroelectronics range on EnvMart for more Operational Amplifiers and semiconductor components tailor-made for your project requirements.
