Wurth Elektronik Wirewound Shielded Surface Mount Inductor 470 μH ±20% 600 mA DC Current 1050 Package WE-PD 7447714471

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik Wirewound Shielded Surface Mount Inductor 470 μH ±20% 600 mA DC Current 1050 Package WE-PD 7447714471

Name: Wurth Elektronik Wirewound Shielded Surface Mount Inductor 470 μH ±20% 600 mA DC Current 1050 Package WE-PD 7447714471
Brand: Wurth Elektronik
SKU: 370923
Price: 2.37 USD
Availability: InStock



Category Surface Mount Inductors Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Brand	Wurth Elektronik
Height	5mm
Length	10mm
Depth	10mm
Packaging	Tape & Reel
Series	WE-PD
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Inductance	470μH
Standards/Approvals	RoHS
Package/Case	1050
Maximum DC Current	600mA
Maximum DC Resistance	1.1Ω
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	2.5MHz
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200

Key Features

Magnetically shielded wirewound design reduces leakage fields effectively.
Suitable for switching regulators with low operating voltages.
Supports operation temperatures from -40°C to 125°C.
Features surface mount termination style for PCB assembly.
Maximum DC resistance of 1.1 ohms ensures efficient performance.
Maximum self-resonant frequency of 2.5 MHz for high-frequency applications.
Packaged in tape and reel format for automated manufacturing processes.
Constructed with high storage capacity and high current loading capability.

Product Description

Wurth Elektronik 7447714471 wirewound shielded surface mount inductor, part of the WE-PD series, delivers reliable inductance of 470 μH with ±20% tolerance and a maximum DC current rating of 600 mA. It features a compact 1050 package case measuring 10 mm length, 5 mm height, and 10 mm depth, designed for efficient surface mounting on PCBs.

This inductor is magnetically shielded to minimize leakage fields, making it ideal for applications requiring electromagnetic compatibility. It complies with the AEC-Q200 automotive standard and RoHS environmental directives.

The WE-PD series is optimized for use in switching regulators, integrated DC-DC converters, and high-efficiency switching regulators exceeding 86% efficiency, suitable for graphic cards and other high-performance electronic devices.

Operating temperature ranges from -40°C up to 125°C, allowing use in a variety of industrial and automotive environments. Its wirewound construction guarantees durability and stable inductance values under thermal stress.

The product is supplied in tape and reel packaging supporting automated placement during PCB assembly, improving production efficiency. The maximum DC resistance is 1.1 ohms with a maximum self-resonant frequency of 2.5 MHz.

This series offers plastic base variants that provide resilience against vibration and shock, suitable for demanding operational conditions. The recommended solder profile is reflow soldering.

Magnetically shielded wirewound design for low leakage field. High current loading and storage capacity. Compliance with AEC-Q200 automotive standard. RoHS certified for environmental compliance. Suitable for switching regulators and DC-DC converters.

Compact 1050 package size with surface mount termination. Operating temperature range from -40°C to 125°C. Tape and reel packaging for automated assembly.

These inductors serve industrial, automotive, and electronic manufacturing sectors requiring efficient power inductors with compact form factors. Explore additional Wurth Elektronik components at EnvMart for comprehensive electronic solutions.
