Eaton DR127-220-R Shielded Surface Mount Inductor with Ferrite Core 22 μH ±20% 7.57 A Idc

Free Delivery in India | Lowest Global Shipping Charges

Eaton DR127-220-R Shielded Surface Mount Inductor with Ferrite Core 22 μH ±20% 7.57 A Idc

Name: Eaton DR127-220-R Shielded Surface Mount Inductor with Ferrite Core 22 μH ±20% 7.57 A Idc
Brand: Eaton
SKU: 367433
Price: 1.21 USD
Availability: InStock



Category Surface Mount Inductors Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Height	8mm
Length	12.5mm
Model	DR127-220-R
Depth	12.5mm
Packaging	Reel
Series	DR
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	22μH
Standards/Approvals	RoHS
Package/Case	0127
Maximum DC Current	7.57A
Pin Count	2
Maximum DC Resistance	39.1mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Wirewound

Key Features

Magnetically shielded wire wound inductor with ferrite core.
Inductance tolerance of ±20% ensures reliable circuit performance.
Designed for surface mount application with 2-pin termination style.
Maximum operating temperature up to 125°C supports harsh environments.
RoHS compliant and moulded for durability and environmental safety.
Compact size with dimensions 12.5mm length, 8mm height, and 12.5mm depth.
Maximum DC resistance of 39.1 milliohms minimizes power loss.
Suitable for noise filtering, DC-DC converters, and power supply circuits.

Product Description

The Eaton DR127-220-R is a shielded surface mount inductor featuring a ferrite core and wirewound construction, delivering an inductance of 22 μH with a tolerance of ±20%. It supports a maximum DC current of 7.57 A and a maximum operating temperature of 125°C, making it ideal for demanding industrial and electronic applications.

This inductor uses a 0127 package/case and is supplied on a reel for efficient automated PCB assembly. Its compact dimensions of 12.5 mm length, 8 mm height, and 12.5 mm depth facilitate integration in space-constrained designs.

The magnetic shielding reduces EMI, enhancing signal integrity in sensitive electronics. This component complies with RoHS standards and is moulded to resist environmental and mechanical stresses.

Applications include use in computers, DVD players, LCD panels, portable devices, and power conversion circuits such as buck, boost, forward, and resonant converters. It is effective in noise filtering and as a filter choke in power supplies.

Eaton, formerly known as Cooper Bussmann, offers this inductor as part of the DR series, designed for high power density, reliability, and long lifecycle in industrial, automotive, and manufacturing environments.

Magnetically shielded wire wound inductor with ferrite core. Inductance tolerance of ±20% ensures reliable circuit performance. Designed for surface mount application with 2-pin termination style. Maximum operating temperature up to 125°C supports harsh environments.

RoHS compliant and moulded for durability and environmental safety. Compact size with dimensions 12.5mm length, 8mm height, and 12.5mm depth. Maximum DC resistance of 39.1 milliohms minimizes power loss. Suitable for noise filtering, DC-DC converters, and power supply circuits.

Wirewound construction provides high power density and efficiency. Explore more Surface Mount Inductors and components in the Electronics & Electricals category at EnvMart for your industrial and electronic design needs.
