onsemi Negative Voltage Regulator 625 mW 40 V DC TO-92 3-Pin MC79L12ABPRAG

onsemi MC79L12ABPRAG is a fixed 12 V negative linear voltage regulator IC designed for through-hole applications with a compact TO-92 3-pin package. It features a power rating of 625 mW, supporting input voltages up to 40 V DC and a minimum input voltage threshold of -13.7 V. The device offers a low quiescent current of 6.5 mA, making it suitable for efficient power management in embedded circuits.

The MC79L12ABPRAG includes intrinsic protections such as internal short circuit current limiting and thermal overload shutdown, enhancing its reliability in industrial and consumer electronics applications. Its maximum operating temperature is rated at 125°C, which supports high-temperature environments.

This regulator requires no external components for standard operation, facilitating a simplified design in power supply circuits that demand a negative fixed voltage output with currents up to 100 mA. Applications include on-card voltage regulation, power management modules in industrial, laboratory, and general-purpose electronic devices.

The TO-92 package provides a reliable through-hole footprint that integrates easily into printed circuit boards (PCBs), suitable for prototyping and production. The product is lead-free and RoHS compliant, supporting environmental safety directives.

Fixed negative 12 V output voltage regulator. 625 mW power rating with up to 100 mA output current capacity. TO-92 3-pin package with through-hole mounting. Internal protections for short circuit and thermal overload. Low quiescent current of 6.5 mA enhances energy efficiency.

Wide input voltage range from -13.7 V to 40 V DC. Maximum operating temperature up to 125°C suitable for harsh environments. Lead-free packaging compliant with environmental safety standards.
