Hirose DF12 Series Straight Surface PCB Socket, 10-Contact, 2 Row, 0.5 mm Pitch Solder DF12

Hirose DF12 Series Straight Surface PCB Socket DF12 is a high-precision 10-contact, 2-row board-to-board connector designed for reliable electrical connections on printed circuit boards. This PCB socket features a compact 0.5 mm pitch with a stacking height of 3 mm, offering ultra-miniature dimensions suitable for space-constrained industrial and electronic applications.

The socket is constructed with a robust polyamide housing that complies with UL94V-0 flammability standards for safety. Gold-plated copper contacts ensure excellent conductivity and corrosion resistance, rated for a current of 300mA and voltage of 50V, supporting stable signal transmission under demanding conditions.

Its surface mount termination type and straight orientation facilitate easy PCB installation. The design includes board retention hardware and location posts to guarantee secure solder retention and mechanical stability during operation.

Operating temperature ranges from -55°C to 125°C, making it suitable for various industrial environments including manufacturing electronics, automotive controls, and power connectors.

Features gold-plated copper contacts for reliable conductivity. Constructed with a polyamide housing material ensuring durability. Supports a maximum operating temperature of 125°C and minimum of -55°C. Operates at 50V with a rated current of 300mA suitable for low power applications.

Surface mount type with straight orientation for compact PCB design. Stacking height is 3mm allowing flexible board stacking configurations. Two rows with a row pitch of 2.4mm enhance connection density. Includes board retention hardware and location posts for secure mounting.

Connector gender is female designed for mating with headers. Ideal for industrial electronics, power connectors, and PCB assembly applications.

This Hirose DF12 PCB Socket is essential for electronic component manufacturers and designers seeking compact and reliable PCB connections with high signal integrity. Explore more connectors and related components in the Electronics & Electricals category on EnvMart.
