DiodesZetex Non-Inverting Open Drain Buffer 14-Pin TSSOP, 1.65 to 5.5V Operating Voltage 74LVC04AT14-13

DiodesZetex 74LVC04AT14-13 is a high-performance non-inverting open drain buffer IC housed in a 14-pin TSSOP package. This device operates over a low voltage range of 1.65 to 5.5 volts, making it suitable for low-voltage digital logic applications. Its CMOS technology provides compatibility with LVTTL and TTL input levels and outputs in LVCMOS format, ideal for modern embedded systems and electronic designs.

The buffer offers a maximum propagation delay time of 9.5 nanoseconds, enabling rapid signal processing in timing-critical applications. Rated for operation between -40°C to 125°C, it delivers reliable performance across industrial temperature ranges. The device features an open drain output with non-inverting polarity allowing for versatile logic interfacing designs.

Its compact 14-pin TSSOP package type facilitates efficient PCB layout and is designed for surface mount technology, supporting automated production processes. The low supply current of approximately 10 microamperes aids in reducing overall power consumption and heat generation, beneficial for battery-powered and low-power systems.

Its robust electrical specifications and compact form factor make it an essential component for electronics engineers and designers focusing on logic buffering and signal integrity.

Key features include non-inverting open drain output, low-voltage operation, and compatibility with TTL and CMOS logic families. This buffer IC is not automotive rated and has no special approvals or certifications listed.

Explore EnvMart’s extensive semiconductor catalog for a broad range of buffer ICs and electronic components to support your industrial, laboratory, HVAC, manufacturing, and commercial project needs.

Supports a logic family of Low-Voltage CMOS (LVC) technology. Features a non-inverting output with open drain type output. Operates within a temperature range of -40°C to 125°C. Has a maximum propagation delay time of 9.5 nanoseconds at CL.

Includes 14 pins in a compact TSSOP package. Input compatibility includes LVTTL and TTL levels, output compatible with LVCMOS. Maximum supply voltage rating is 5.5 V with minimum at 1.65 V. Low supply current typical at 10 μA enhances energy efficiency.

Designed for surface mount technology for PCB assembly. Manufactured in China, ensuring quality control compliance. Browse more high-quality Buffer ICs and semiconductor products at EnvMart.
