ROHM Non-Inverting CMOS Buffer, 1-Channel, 5-Pin SSOP-5, 1.65-5.5V Supply, 10ns Propagation Delay BD7LS125G-CTL

Free Delivery in India | Lowest Global Shipping Charges

ROHM Non-Inverting CMOS Buffer, 1-Channel, 5-Pin SSOP-5, 1.65-5.5V Supply, 10ns Propagation Delay BD7LS125G-CTL

Name: ROHM Non-Inverting CMOS Buffer, 1-Channel, 5-Pin SSOP-5, 1.65-5.5V Supply, 10ns Propagation Delay BD7LS125G-CTL
Brand: ROHM
SKU: 177318
Price: 0.27 USD
Availability: InStock



Category Buffer IC Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Height	2.8mm
Length	2.9mm
Model	BD7LS125G-CTL
Mount Type	PCB
Output type	CMOS
Series	BD7LS07G
Input Type	CMOS
Maximum Operating Temperature	125°C
Package Type	SSOP-5
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
Number Of Channels	1
Standards/Approvals	RoHS
Pin Count	5
Automotive Standard	AEC-Q100
Maximum Supply Voltage	5.5V
Logic Family	CMOS
Logic Function	Buffer
Minimum Supply Voltage	1.65V
Maximum High Level Output Current	24mA
Maximum Propagation Delay Time @ CL	10ns
Supply Current	10μA

Key Features

Operates from a minimum supply voltage of 1.65V to a maximum of 5.5V.
Features a 5-pin SSOP package ensuring compact footprint on PCB.
Maximum propagation delay time is 10 nanoseconds at CL.
Output tolerant supports partial power down mode operation to prevent back flow current.
Maximum high and low level output current is 24mA each for strong output drive capabilities.
Complies with RoHS standards and is AEC-Q100 qualified for automotive use.
Device features low supply current consumption of 10 microamperes.
Operating temperature range from -40°C to 125°C for wide environmental tolerance.

Product Description

ROHM BD7LS125G-CTL is a non-inverting CMOS buffer in a compact 5-pin SSOP-5 package, providing a single logic channel optimized for power-efficient operation at supply voltages from 1.65V up to 5.5V. This device delivers a maximum propagation delay of 10 nanoseconds at capacitive load, meeting the demands for fast digital signal buffering in modern semiconductor applications.

Designed to operate in automotive environments, it conforms to the AEC-Q100 automotive standard and the RoHS directive, ensuring reliability and environmental compliance. The buffer features output tolerant inputs that protect against back flow currents when in power down mode, increasing robustness in complex systems.

Its maximum high and low level output current is 24mA, providing strong signal drive capabilities suitable for interfacing with a variety of CMOS logic levels. The device consumes a low supply current of just 10 microamperes, enhancing energy efficiency in low power applications.

The operational temperature range extends from -40°C to 125°C, allowing deployment in harsh industrial and automotive conditions. The SSOP-5 package size is ideal for space-constrained PCB designs requiring reliable buffering performance.

Operates from 1.65V to 5.5V supply voltage. Single channel CMOS non-inverting buffer with output tolerance. 5-pin SSOP package minimizes board footprint. Compliant with RoHS and AEC-Q100 automotive qualification. Low supply current of 10μA for energy efficient operation.

Fast propagation delay of 10ns at capacitive load. Output high/low current up to 24mA. Wide temperature operating range -40°C to 125°C. Protected output stage prevents back flow current during power down.

This Buffer IC is ideal for use in industrial electronics, automotive electronic control units, consumer electronics, and any applications requiring reliable, fast, and low power digital signal buffering. Explore more semiconductor and logic IC products on EnvMart for comprehensive component sourcing.
