MaxLinear CMOS Line Transceiver, Differential Input/Output, Inverting Polarity, 8-Pin SOIC SP3078EEN-L

The MaxLinear SP3078EEN-L is a high-performance CMOS line transceiver designed for industrial and electronic applications requiring differential signal transmission with inverting polarity. This device features a single channel line transceiver IC with differential input and output, optimized for robust communication in RS-485 and RS-422 networks.

Operating over a supply voltage range from 5V to 6V, the transceiver exhibits a low supply current of 1.5mA, which makes it suitable for energy-efficient designs. It offers a maximum propagation delay of 75ns at capacitive load, allowing for fast data transmission speeds. The device is built in a compact 8-pin SOIC surface mount package, measuring 4.9mm in length, 3.9mm in width, and 1.75mm in height, which supports high-density PCB layouts.

This line transceiver is rated for operation in harsh environments with a wide temperature range from -40°C to 85°C. It does not bear any specific industry approvals but is compliant with common RS-485 line standards. Its inverting polarity feature supports applications requiring signal inversion, enhancing design flexibility.

The MaxLinear SP3078EEN-L is ideal for use in industrial control, automation systems, and general data communication where reliable differential signaling is crucial. Its surface mount form factor ensures streamlined integration on modern printed circuit boards.

CMOS technology ensures low power operation. Differential input and output maximize signal integrity under noisy conditions. Inverting output polarity supports diverse design requirements. Compact SOIC package optimizes board space.

Operational temperature range accommodates industrial environments. Low supply current enables power-sensitive applications. Fast propagation delay improves communication speed. Suitable for RS-485 and RS-422 serial communication standards.

Surface mount design facilitates automated assembly. Reliable and robust line driver solution for industrial electronics. Explore more semiconductor products and line transceivers at EnvMart for advanced industrial, electronic, and communication solutions.
