Eaton Non-Resettable Fuse Radial 500mA 250V AC Time Delay Plastic Body SS-5-500MA-BK

Free Delivery in India | Lowest Global Shipping Charges

Eaton Non-Resettable Fuse Radial 500mA 250V AC Time Delay Plastic Body SS-5-500MA-BK

Name: Eaton Non-Resettable Fuse Radial 500mA 250V AC Time Delay Plastic Body SS-5-500MA-BK
Brand: Eaton
SKU: 367246
Price: 1.35 USD
Availability: InStock



Category Fuse Brand Eaton Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Diameter	0.6mm
Brand	Eaton
Body Material	Plastic
Height	8.35mm
Length	8.5mm
Model	SS-5-500MA-BK
Width	4.3mm
Current Rating	500mA
Series	SS5
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Lead Length	4.3mm
Breaking Capacity	35A
Standards/Approvals	IEC 600680, VDE, RoHS, UL 94V0
Fuse Characteristics	Time Delay
Lead Orientation	Radial

Key Features

The fuse features a time-delay characteristic suited for protecting sensitive electronic circuits.
It has a compact plastic body designed to minimize PCB space requirements.
Operating temperature ranges from -40°C minimum to 125°C maximum ensuring robust performance.
Breaking capacity is rated at 35A, providing adequate protection in various applications.
The fuse leads are radial with a length of 4.3mm and diameter of 0.6mm for secure PCB mounting.
Compliance includes IEC 600680, VDE, RoHS, and UL 94V0 standards for safety and reliability.
Made in China with Cooper Bussmann SS-5 series time-delay subminiature fuses ideal for PCB circuit protection.

Product Description

Eaton SS-5-500MA-BK non-resettable fuse with radial lead orientation, rated at 500mA current and 250V AC voltage, provides reliable time-delay circuit protection. This fuse features a compact plastic thermoplastic polyamide body that efficiently minimizes PCB footprint, making it suitable for dense electronic assemblies.

Key physical dimensions are 8.5mm length, 4.3mm width, and 8.35mm height with radial leads measuring 4.3mm in length and 0.6mm in diameter for secure and easy PCB mounting.

The fuse is designed to perform under extreme conditions with an operating temperature range from -40°C to 125°C, supporting durability in harsh industrial and electronic environments.

With a breaking capacity of 35A, it effectively protects circuits by interrupting excessive current and preventing damage in electrical and automation systems.

Certified to IEC 600680, VDE, RoHS, and UL 94V0 standards, this Eaton fuse meets stringent safety and quality requirements for industrial, manufacturing, and electronic applications.

Manufactured in China, it belongs to the Cooper Bussmann SS-5 series of time-delay subminiature fuses, widely used in PCB circuit protection across sectors like industrial automation, electrical manufacturing, and commercial electronics.

The Fuse’s time-delay characteristic allows transient currents without nuisance blowing. The small rectangular-leaded design helps in saving PCB space. Thermoplastic polyamide body ensures mechanical strength and flammability resistance.

Its radial lead configuration provides stable mounting on printed circuit boards. Suitable for use in electrical, automation, and control panel manufacturing industries. Ensures compliance with international safety standards and environmental regulations.

Offers dependable electrical circuit safeguarding in demanding industrial environments. Compact size and excellent electrical characteristics enable integration into various electronic equipment. Explore the Eaton range at EnvMart for trusted electrical protection components designed for long-term reliability and safety.
