Crydom Solid State Relay Panel Mount 20A Load 72V DC Load 32V DC Control DC100D20C
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 32.9mm |
| Length | 58.2mm |
| Model | DC100D20C |
| IP Rating | IP20 |
| Width | 22.6mm |
| Mount Type | Panel |
| Output type | MOSFET |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Capacitance | 8pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Switching Function | Instantaneous Switching |
| Maximum Load Current | 20A |
| Standards/Approvals | UL, RoHS, CE |
| Maximum Load Voltage | 72V dc |
| Minimum Load Voltage | 1V dc |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 0.15mA |
| On State Resistance | 15Ω |
Key Features
- Panel mount type solid state relay with screw terminal connections.
- Maximum load current of 20 amperes.
- Operates with load voltages from 1V DC up to 72V DC.
- Control voltages range between 4V DC minimum and 32V DC maximum.
- Utilizes MOSFET output for low on-state resistance of 15 ohms.
- Instantaneous switching function for efficient control.
- Rated operating temperatures from -30°C to 80°C.
- Off state leakage current of 0.15 mA ensuring minimal power loss.
Product Description
Crydom DC100D20C solid state relay is a panel mount device engineered to handle a maximum load current of 20 amperes at up to 72 volts DC. Featuring screw-type terminal connections, this relay provides reliable electrical isolation and switching for DC loads in industrial and automation applications. It supports control voltages from 4V DC minimum to 32V DC maximum.
The relay employs optically isolated MOSFET output technology, offering low on-state resistance of 15 ohms which reduces heat generation and power loss. Its instantaneous switching function allows for fast and precise load control, ideal for equipment requiring swift response times.
With operational temperatures ranging from -30°C to 80°C and an IP20 protection rating, this relay is suited for panel mount configurations in control panels and automation systems across industrial, manufacturing, and electrical sectors.
Physical dimensions of this unit are compact with a length of 58.2 mm, width of 22.6 mm, and a height of 32.9 mm, facilitating integration into a variety of control hardware.
This solid state relay complies with recognized safety and quality standards including UL, RoHS, and CE, ensuring dependable operation in critical applications. The device's minimal off-state leakage current of 0.15 mA further enhances energy efficiency.
Panel mount type solid state relay with screw terminal connections. Maximum load current capacity of 20 amperes. Supports load voltages from 1V DC to 72V DC. Control voltage range from 4V DC up to 32V DC. MOSFET output with low on-state resistance of 15 ohms.
Instantaneous switching for responsive control. Compact size: 58.2 x 22.6 x 32.9 mm. Operating temperature range: -30°C to 80°C. Low off state leakage current of 0.15 mA. Approved by UL, RoHS, and CE standards.
This solid state relay is extensively used for industrial automation, electrical control panels, manufacturing equipment, and power management systems. Its reliable switching and compact design make it ideal for demanding electrical environments.
Explore further products within the Solid State Relays category on EnvMart for comprehensive industrial relay solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this relay is 20 amperes.
It supports load voltages from 1V DC up to 72V DC.
The control voltage range for this relay is from 4V DC minimum to 32V DC maximum.
This model utilizes MOSFET output technology, which provides low on-state resistance.
The dimensions of this relay are 58.2 mm in length, 22.6 mm in width, and 32.9 mm in height.
It operates within a temperature range of -30°C to 80°C.
The off-state leakage current is 0.15 mA, ensuring minimal power loss.
This relay features screw terminal connections for reliable electrical isolation.
The IP rating for this relay is IP20.
It complies with UL, RoHS, and CE standards, ensuring safety and quality.
This model provides instantaneous switching for efficient load control.
It is suitable for industrial automation, electrical control panels, manufacturing equipment, and power management systems.
